| Brand Name : | Morel |
| Model Number : | Morel - F10 |
| Certification : | CE,ISO9001 |
| Price : | Negotiation |
| Payment Terms : | T/T, Western Union, MoneyGram,Paypal |
| Supply Ability : | 500/month |
| Delivery Time : | 2-3days |
| Model | Morel F10 | |
Heating System | Number of heating zones | Top 10/ bottom 10 |
| Number of cooling zones | 2(top 1, bottom 1) | |
| Heating passage | 3700mm | |
| Heating style | Hot air | |
| Cooling style | Forced air cooling | |
| Exhaust Volume | 10m³/min * 2 vanes | |
Conveyor System | Max. Width of PCB | 400mm |
| Mesh belt width | 450mm | |
| Conveyor Direction | L→R(option: R→L) | |
| Process Height | 900±20mm | |
| Conveyor type | Mesh and chain | |
| Range of rail width | 50-400mm | |
| Conveyor speed | 0-2000mm/min | |
| Auto/manual Lubrication | Standard | |
| Fixed Track | Front track fixed(option: rear track fixed) | |
| Product clearance | Top and bottom 25mm | |
Control system | Power supply | 5 line 3 phase 380V 50/60HZ |
| Total power | 58KW | |
| Startup power | 50KW | |
| Steady consumption | 10KW | |
| Ramp up time | 20 mins | |
| Temp. setting range | From room temp. To 300℃ | |
| Temp. control method | PID close loop control & SSR driving | |
| Temp. control precision | ±1℃ | |
| Temp. deviation on PCB | ±2℃ | |
| Data storage | Process Data and status storage(80GB) | |
| Nozzle plate | Aluminum Alloy Plate | |
| Abnormal Alarm | Abnormal temperature (overtemp/low temperature) | |
| Board dropped alarm | Tower light: Amber-warming, Green-normal, Red-abnormal | |
General | Dimension(L*W*H) | 5400*1320*1490mm |
| Weight | 2300kg | |
| Color | Computer gray | |


|
