    Galvanized Wire Army Flood Protection Defensive Barrier Sand Wall

    Ask Lasest Price
    Brand Name : SHUXIN
    Model Number : 1mx1m
    Certification : ISO CE SGS COC
    Price : Negotiated
    Payment Terms : Western Union, MoneyGram, T/T, L/C
    Delivery Time : 15 working days
    Supply Ability : 100 units per week
    • Product Details
    • Company Profile

    Galvanized Wire Army Flood Protection Defensive Barrier Sand Wall

    Galvanized Wire Army Flood Protection Defensive Barrier Sand Wall


    Introduction of Defensive Barrier :

    Defensive Barrier also known as Rock basket retaining wall, flood control barrier, etc. which is made of the steel welded mesh and lined with non-woven geotextile, can be filled with sand, earth, cement, stone, then as a defensive wall or bunker and widely used in the military to protect safety.

    Defensive Barrier Features :

    1. A pre-fabricated gabion of galvanized welded mesh steel fitted with a UV-protecting.
    2. Polypropylene geo-textile liner.
    3. Filling material is an easy- obtained mix of sand and small stones.
    4. It can be used together to any length, and can be stacked for additional height.

    Specification of Defensive barrier :
    1) wire diameter: 4mm-5mm
    2) hole: 2''x2'',3''x3'',4''x4''
    3) hesco size: 0.61x0.61m,1x1m,2.13x2.21m,other size can be produced as requested.
    4) geotextile: in non-woven geotextile,color can be green,beige-sand color.


    Specification


    ModelHeightWidthLengthInternal Cells
    SX-1(Mil 1)54”(1.37m)42”(1.06m)32’9”(10m)5+4=9 cells
    SX-2(Mil 2)24”(0.61m)24”(0.61m)4’(1.22m)2 cells
    SX-3(Mil 3)39”(1.0m)39”(1.0m)32’9”(10m)5+5=10 cells
    SX-4(Mil 4)39”(1.0m)60”(1.52m)32’9”(10m)5+5=10 cells
    SX-5(Mil 5)24”(0.61m)24”(0.61m)10’(3.05m)5 cells
    SX-6(Mil 6)66”(1.68m)24”(0.61m)10’(3.05m)5 cells
    SX-7(Mil 7)87”(2.21m)84”(2.13m)91’(27.74m)5+4+4=13 cells
    SX-8(Mil 8)54”(1.37m)48”(1.22m)32’9”(10m)5+4=9 cells
    SX-9(Mil 9)39”(1.0m)30”(0.76m)30’(9.14m)6+6=12 cells
    SX-10(Mil 10)87”(2.21m)60”(1.52m)100’(30.5m)5+5+5+5=20 cells
    SX-11(Mil 11)48”(1.22m)12”(0.30m)4’(1.22m)2 cells
    SX-12(Mil 12)84”(2.13m)42”(1.06m)108’(33m)5+5+5+5+5+5=30 cells
    SX-19(Mil 19)108”(2.74m)42”(1.06m)10’5”(3.18m)6 cells

    Defensive Barrier Application :


    1. landscaping, as retaining walls, landscape urban landscape and parks.
    2. or high salt pollution in the environment, Gore can be used where welded wire mesh technology.
    3. within the welded wire mesh filled with stone or natural cobblestone highway together protection, slope, roadway, bridge and so on.
    4. welded wire mesh is widely used in earth or soil reinforcement such as desertification, slope protection, river, coastal protection, reservoirs, canals and pipelines renovation, Rock failure protection, bridge protection, protective net.
