    220V Flap Barrier Gate With Enhanced Functions

    Ask Lasest Price
    Brand Name : WEJOIN
    Model Number : WJTY201
    Certification : CE,ISO,SGS
    Payment Terms : T/T
    • Product Details
    • Company Profile

    220V Flap Barrier Gate With Enhanced Functions

    Flap Barrier Gate With Enhanced Functions


    This flap barrier gate is the combination of machinery, electronic, CPU control and variety of personal

    authentication identification technology.It can be compatible with IC card, ID card, code bar, and fingerprint

    identification unit.WEJOIN flap barrier has features of precise craftsmanship, comprehensive functions and hightechnology. It has application in high class communities, intelligent buildings, hotels, subway stations and so on .


    Functions and Features

    1.Auto reset function, after the flap open if no pedestrian passes in a fixed time, the system will cancel the order

    and the auto-reset time is adjustable.

    2. Flaps open when power off, and auto-close when power on.

    3. Compatible with diverse access control devices.

    4. Pedestrian flow directions can be single or double directions.

    5. Available for two-way traffic lights, which can prompt the state---pass or no-entry.

    6. RS232 and LAN sockets are available to connect the computer.

    7. The design is of integration of machinery and electronic structure, with special drive style and reliable

    machinery auto locking solution, precise worm gear, and cabinet composite structure.

    8. Malfunction self-detection. Which is easy for operation and maintenance.

    9. Operational mode can be set up through the built-in menu on the control board.

    10. Flap auto reversing when meeting exterior force.

    11. Audible and visual alarm in case of unauthorized access.

    12. Auti-collision function, the flap will stay close if not receiving the open signal.

    13. Flap work synchronously.


    ModelWJTY201
    Stretching-out flap length275mm
    The max lane width600mm
    Cabinet materialCold rolled steel & aluminum alloy
    Material of Flap DoorOrganic glass
    Housing of thickness1.5mm
    Normal Life Span3 millions times
    Communication InterfaceStandard RS485(distance less than 1200 meters)
    Transit speed30-40 persons/min
    Time for opening or closing0.5s
    Starting time after power on3s
    Input interfaceDry contact signal or +12Vor pulse signal with width more than100ms DC12V
    Transit speed25~32 persons/min
    Working temperature-10°C~50°C
    Working environmentIndoor / Outdoor (Shelter)
    Relative humidity≤95%, no condensation
