Features
1.Low dew point: up to -40℃
2. Ease of maintenance of access process, regeneration, and air
filters
3. Self-adaptive PID temperature control from 60℃ to 180℃
4. No use of cooling water
5. No moving or rotating internal parts
6. No need of manual control, Full auto-adaptive operation
7. On-board heating unit on hopper for less energy loss
CSG series is a fully automatic drying system with zeolite
desiccant beds, which Can be used with Hopper Bank Series and
multi-hopper systems. It can adapt and automatically control
operating parameters based on type and quantity of polymer. Up to
40% energy saving in comparison with traditional dryers
Some plastic materials are hygroscopic. They hold water molecules
similarly to a sponge.
These plastics must always be dried before they are processed.
Otherwise the molding process will result in sub-standard parts.
Streaks and insufficient strength can be traced back to a lack of
or insufficient drying.
Criteria for the drying process:
The residual humidity
... is the moisture content that remains after the material has
been dried. The permitted level of maximum residual humidity varies
according to the material.
The drying time
... is the time in which the material is dried to a required level.
The drying temperature
... is the temperature at which the plastic granulate is dried.
The holding time
... is the total time that the granulate spends in the dryer, from
filling to conveying.
Dry air
... is warm air from which the moisture has been removed. As warm
air absorbs more water than cold air, the moisture is drawn out of
the granulate.
The dew point
... in plastic granulate drying is the temperature at which
moisture condenses out of the air onto the material. The lower the
dew point, the dryer the air.
The series dehumidifier can automatically adjust the control
parameters according to various temperature changes, such as
material temperature and air temperature, so as to achieve
intelligent control, improve efficiency and save energy.
