    Nema 34 Hybrid Stepper Motor high torque 12.5N.m 155mm Length for CNC machine

    Ask Lasest Price
    Brand Name : Jkongmotor
    Model Number : JK86HS155-6004
    Certification : CE, ROHS,ISO9001
    Price : US$36.5~US$49
    Payment Terms : T/T , paypal , Western Union, L/C
    Supply Ability : 100000pcs/month
    Delivery Time : For samples , 7-15 days / For batch , 15-25days
    MOQ : 10pcs
    • Product Details
    • Company Profile

    Nema 34 Hybrid Stepper Motor high torque 12.5N.m 155mm Length for CNC machine

    1Axis Nema 34 Hybrid Stepper Motor high torque 12.5N.m 155mm Length for CNC machine

    1.Genaral Specification of high torque nema 34 stepper motor:

    ItemSpecifications
    Step Angle0.9°
    Temperature Rise80℃max
    Ambient Temperature-20℃~+50℃
    Insulation Resistance100 MΩ Min. ,500VDC
    Dielectric Strength500VAC for 1minute
    Shaft Radial Play0.02Max. (450g-load)
    Shaft Axial Play0.08Max. (450g-load)
    Max. radial force220N(20mm from the flange)
    Max. axial force60N

    2.Electrical Specification of Fulling motor FL86STH156-6004A:

    Model No.

    Motor Length

    Current

    /Phase

    Resistance

    /Phase

    Inductance

    /Phase

    Holding Torque

    # of Leads

    Detent Torque

    Rotor Inertia

    Mass

    (L)mmAΩmHN.mNo.Kg.cmg.cmKg
    JK86HS155-60041556.00.689.013.043.640005.4


    Matching Stepper motor Driver: JKD7208S OR JKD2060AC

    4.Drawing

    5. Matched Driver DM860H


    1.The latest 32-bit digital processing technology
    2. Advanced control algorithm for variable current and variable frequency conversion
    3. Low heat generation, low motor vibration and stable operation
    4. Built-in micro-segmentation
    5. Smooth operation and low noise
    6. Integrated parameter power-on auto-tuning function
    7. Subdivision setting (within 400~51200)
    8. With overcurrent, overvoltage, undervoltage protection
    • As a comprehensive enterprise with an integration of R&D, design, production, we have highly effcient production line, advanced quality testing instruments, excellentproducts and packing
    • Our company has passed the international quality system authentication of CE and ROHS
    • We enjoy a good reputation and sell productions to dozens of countries.
    • We insist that quality and honesty come first.
    • Anny will be very happy to answer your questions in 24 hours.
