    Sunlight Resistant PV Connectors PC Material High Voltage Carrying Capacity


    TUV approved IP67 Imported PC connector 1000V DC Black 30A 25years warranty


    Description:


    Type: connector PV004
    Electrical Features:
    Rated Current25A(2.5/4mm2),30A(4/6mm2)
    Withstanding Voltage1000V DC(TUV),600V(UL)
    Contact Resistance≤0.3mΩ
    Protection ClassClass II
    Mechanical Features:
    Temperature Range-40 oC~+90oC
    Protection DegreeIP2X,unmated;IP67,mated
    Wire Size Range2.5/4/6mm2(14AWG,12AWG,10AWG)
    Unmating Force200 Newton
    Material Features:
    Insulation MaterialPC
    Contact MaterialCopper,Tin plated
    Flame ClassUL94-V0 or UL94-5VA

    Advantage:


    • Simple,quick,safe and effective filed assembly

    • Develop independently,innovative design,have independent intellectual property rights,adaptive to connector directly

    • High mechanical endurance

    • High current and voltage carrying:30A,1000VDC

    • Low transition resistance

    • Innovative sealed,waterproof,dust resistance design:IP68

    • Excellent plastic material ,UL 94-V0,wide temperature range:-40°c to 90°c,weather and UV resistant for long-time outdoor application

    • Approved by TUV
