    Safety Residential Solar Panels , Solar Pv Modules 60 M / S Load Capacity

    Ask Lasest Price
    Brand Name : Yingli/Jinko
    Certification : ISO9001/CE
    Price : Negotiation
    Payment Terms : LC/TT
    Supply Ability : 5000000 Watt/Watts per Month
    Delivery Time : Shipped in 7 days after payment
    • Product Details
    • Company Profile

    Safety Residential Solar Panels , Solar Pv Modules 60 M / S Load Capacity

    Pv Moudle Serials For Europe,iran And India,pv Moudle,solar Panel,solar Cells


    The specification of 175W mono-crystalline solar module

    TEM NO175/24V
    MONO or POLYMono
    Maximum power (Wp)175wp
    Maximum power voltage (V)35.8
    Maximum power current (A)4.9
    Open circuit voltage (V)44.7
    Short circuit current (A)5.18
    Number of cells (Pcs)72
    Size of module (mm)1580*808*40mm( 125x125mm cell)
    Maximum system voltage (V)1000
    Temperature coefficients of Isc (%)+ 0.1/ ℃
    Temperature coefficients of Voc (%)-0.38/ ℃
    Temperature coefficients of Pm (%)-0.47/ ℃
    Temperature coefficients of Im (%)+0.1/ ℃
    Temperature coefficients of Vm (%)-0.38/ ℃
    Temperature Range-40℃～+80℃
    Tolerance Wattage (e.g. +/-5%)+/-5%
    Surface Maximum Load Capacity60m/s(200kg/sq.m)
    Allowable Hail Load256g steel ball fall down from 1m height
    Weight per piece (kg)16
    Junction Box TypePV-RH0301( TUV )
    Connectors and Cables Type
    Length of Cables (mm)900mm
    Cell Efficiency (%)＞16.4%
    Module Efficiency (%)＞13.7%
    Output tolerance (%)+/-5%
    Frame (Material, Corners, etc.)Aluminum
    Backing (Brand, type)
    Standard Test ConditionsAM1.5 100mW/cm2 25’C
    Warranty2 years product warranty and 25 years 80% of power
    FF (%)73%
    Packing2PCS/CTN ,600PCS/300CTN/40 FCL
    Packing Dimension1630*855*140mm


    Conditions and terms:
    - MOQ: 5000W/Item
    - Trade terms:FOB Shenzhen
    - Lead Time: 20 days
    - Payment Term: T/T 30% downpayment, 70% before delivery
    - Warranty:5 years for solar panel


    Product field:

    1. Gird-connected power generation system

    2. Off-grid power generation system

    3. Building-integrated power generation facilities

    We have a wild range of successful project all over the world.

    We have advanced ,mature and stable supply production line, support your request on solar market.
