Long Item Heavy Duty Gooseneck Trailer Numerical Control , Heavy Equipment Flatbed Trailers Extendable

Long Item Heavy Duty Gooseneck Trailer Numerical Control , Heavy Equipment Flatbed Trailers Extendable

Description:

• Main Usage

The extendable trailer can transport lengthy cargoes. The retractable mechanical spring is designed to control the length. The frame can be extended to fit for the line-haul of a great deal of goods.

• Extendable Performance

After removing the iron bolt, the first folded crossbeam will be drawn out by the force offered by the driving vehicle. For carrying more goods, the length can be readjusted by removing second iron bolt. It is important to note that the bolt can’t be removed at the same time but can be fixed when folding the frame.

Advantages:

• Numerical Control

The hole of the main beam is punched by numerical control machine. The welding is automatically completed by submerged arc furnace. Any joints are not found in the integrated main beam. Materials are processed by CNC cutting.

• Lightweight Material

Steel plate is used to produce the main beam. The light steel with high strength can make the weight and load of the vehicle reduced and improved respectively. Moreover, abrasion and deformation can be resisted.

• Bias Tire

The bias tire approved by engineering vehicles is adopted to offer the better elasticity and abrasion resistant.

Specifications:

Dimension	12400×2500×1540(mm)
Kingpin Setting	800(mm)
Kingpin Plate Height	1203(mm)
Wheel Base	7400mm+1310mm+1310mm
Tare Weight	7500kg
Payload	40000kg
G.V.W.R	47500kg
Landing Gear	Two speed manual operation type
Kingpin	3.5" welded type
Brake System	Dual line pneumatic brake system
ABS	YES
Brake Chamber	Type 30/30 spring brake system on all axles
Suspension	Tandem type
Axle	FUWA / BPW axle, 13 ton capacity/set, 3PCS
Tire	12.00R20, 12PCS
Rim	8.5-20, 12PCS
Floor	3mm checked plate
Twist Lock	12 sets
Main Beam	500/14/6/16
Side Beam	16# channel steel
Cross Beam	Square tube
Tool Box	1 pcs
Spare Tire Carrier	2 units
Gallery

Company Profile:

Hubei Huilong Special Vehicle Co.,Ltd is a special purpose vehicle manufacturer located in Suizhou - Capital of Special Vehicles in China.

Our products are produced with the greatest attention on the operation, road safety and environmental protection. Lightweight design on structures and materials is applied for our vehicles. Saving energy is also considered. Emission standards (Euro 3 - 5) are strictly followed. Due to the advanced technology and high added value, our products are popular with the market.

Huilong factory designs and produces a wide range of special vehicles, covering tank trailer, LPG trailer, flatbed trailer, lowbed trailer, self-propelled modular transporter (SPMT), tipper trailer, car carrier trailer, caravan trailer, tank truck, LPG truck, tow truck, fire truck, ambulance, asphalt truck, food truck, tractor etc.

Marketing:

Our company has developed a global marketing network. Our products are exported to countries and areas all over the world, like Africa, South East Asia, Middle East and Australia.
