    High Efficiency Mobile Water Well Drilling Rigs / Hydraulic Water Well Drilling Machine

    Ask Lasest Price
    Model Number : XY-2
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : L/C, D/A, T/T, Western Union
    Supply Ability : 2000set/year
    Delivery Time : Within 7-12 days
    Brand Name : ShiTan
    • Product Details
    • Company Profile

    High Efficiency Mobile Water Well Drilling Rigs / Hydraulic Water Well Drilling Machine

    High Efficiency Mobile Water Well Drilling Rigs / Hydraulic Water Well Drilling Machine
    Product Description

    xy-2 is a core drilling rig for middle and shallow hole. It applies not only to alloy and diamond core drilling with different calibres but also can be used for geological prospecting works, drilling of fluid mineral in superficial layer and shot holes and ventilation holes drilling, drilling on hydrology, water wells and big calibres. It has been widely used on areas such as road and railway construction, water resources and hydropower and architecture.


    Technical Specifications



    portable core drilling rig


    Drilling capacity(m)
    AQ wire-line rod560
    BQ wire-line rod350
    NQ wire-line rod250
    42 rod530

    Spindle speed(r/min)

    Forward
    65;114;180;248;
    310;538;849;1172

    Reverse
    51;242

    Max torque (Nm)
    2760

    Angle reange
    0-90°

    Spindle max pull force(KN)
    60

    Spindle stroke (mm)
    600

    Hoist max life capacity with single rope (KN)
    30

    Spindle inner dia (mm)
    76

    Oil pump
    SCB32/12

    Power unit

    Electric motor
    Y180L-4,22Kw

    Diesel engine
    395K2,19.85Kw

    Inner dia of spindle (mm)
    2150×900×1690

    Drill body weight (excluding power)(kg)
    950

    application:


    XY-2 hydraulic feed core drill is small and light weighted, mainly used in shallow and medium deep diamond tungsten carbide core drilling, can also be used in engineering geological, hydro-geological, water well and pile grouting hole drilling.
