supply for all connectors
1. Barometric pressure: 70~106Kpa Relative
2.Humidity: 10~90% (non-condensing)
3.Operating pressure range: -50 ~ + 300 mmHg
4.Sensitivity: 5.0μV/V/mmHg ±3%
5.Nonlinearity and hysteresis: full-scale reading±1.5%
6.Input impedance: 1200Ω ~3200Ω
7.Output impedance: 300±5%
8.Zero pressure offset: -20mmHg~+20mmHg
9.Thermal offset shift: ≤±0.3mmHg/°C
10.Offset drift: After warm-up for 20 seconds, drift within 2 mmHg
within 8 hours
11.Thermal span shift: ≤±0.1%/°C
12.Frequency response: Standard pressure set (48 "/ 12") is 40 Hz;
Separate sensor > 200 Hz
13.Defibrillator withstand: Defibrillation depends on the final
connection of the equipment.
14.Leakage current: Leakage current is dependent on the final
connection of the equipment
15.Overpressure load: -400~+4000mmHg
16.Shock resistance : Withstand falling from one meter for three
times
17.Light sensitivity: When exposed to a 3400°K tungsten light,
candle light at 3000 feet, it's less than 1 mmHg under rated
voltage.
18.Contact with the human body: ≤96h
19.Storage and transport environment requirements: - 20 ° C~ + 60 °
C, < 90%(non-condensing), no corrosive gas and indoor
ventilation, and to avoid high temperature and cold.
20. Product shelf-life: 3 years.
| Category | IBP |
|---|
| Certifications | CE, ISO |
|---|
| Connector Distal | Utah Connector |
|---|
| Hose Diameter | Infusion tube: outer diameter 4.00±0.10mm, inner diameter
2.85±0.10mm |
|---|
| Hose Length | 20 +130 + 150 cm |
|---|
| Hose Material | PVC Jacket |
|---|
| Hose Patient Size | Adult/Pediatric/Neo |
|---|
