    Manganese Copper Electric Resistant Wire Good Stability For Emitter Resistor

    Ask Lasest Price
    Brand Name : TANKII
    Model Number : 6J12
    Certification : ISO9001:2008
    Price : To negotiate
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 20+TON+MONTH
    Delivery Time : 7-12 days
    • Product Details
    • Company Profile

    Manganese Copper Electric Resistant Wire Good Stability For Emitter Resistor

    Manganese Copper Electric Resistant Wire Good Stability For Emitter Resistor


    Product Description:

    Manganin alloy is one kind of electric resistance alloy which is mainly made of copper, manganese and nickel.

    It has character of small resistance temperature coefficient,low thermal EMF vs copper E,outstanding long-term stability,good weldability and workability,which makes it to be superior precision surveying instrument.such as resistor measure voltage/current/resistance and more.

    It is also high-quality electric heating wire for low-temperature heating element,such as heater of air-conditioning system,household heating appliances.


    Manganin is a trademarked name for an alloy of typically 84% copper, 12% manganese and 4% nickel.

    Manganin foil and wire is used in the manufacture of resistors, particularly ammeter shunts, because of its virtually zero temperature coefficient of resistance value and long term stability. Several Manganin resistors served as the legal standard for the ohm in the United States from 1901 to 1990. Manganin wire is also used as an electrical conductor in cryogenic systems, minimizing heat transfer between points which need electrical connections.

    Manganin is also used in gauges for studies of high-pressure shock waves (such as those generated from the detonation of explosives) because it has low strain sensitivity but high hydrostatic pressure sensitivity.


    Manganin alloy series:

    6J8,6J12,6J13


    Size dimension range:

    Wire: 0.018-10mm

    Ribbons: 0.05*0.2-2.0*6.0mm

    Strip: 0.05*5.0-5.0*250mm


    TypeElectrical resistivity
    (20degreeΩ
    mm²/m)
    temperature coefficient of resistance
    (10^6/degree)
    Dens
    ity
    g/mm²
    Max. temperature
    (°c)
    Melting point
    (°c)
    CuNi10.03<10008.9/1085
    CuNi20.05<12008.9
    200
    1090
    CuNi60.10<6008.92201095
    CuNi80.12<5708.92501097
    CuNi100.15<5008.92501100
    CuNi140.20<3808.93001115
    CuNi190.25<2508.93001135
    CuNi230.30<1608.93001150
    CuNi300.35<1008.93501170
    CuNi340.40-08.93501180
    CuNi400.48±408.94001280
    CuNi440.49<-68.94001280

    Advantages

    Advantages1. Low electric resisitance
    2. Wide temperature range
    3. Good heat resistant and corrosotion resisitant
    4. Easy to be processed and lead welded
    5. Cheaper than nichrome wire

    Product Application:
