    Flame - Retardant Automotive Braided Sleeving With Abrasion Resistance

    Ask Lasest Price
    Brand Name : Huiyunhai
    Model Number : HYH
    Certification : UL, RoHS, REACH
    Price : Negotiable
    • Product Details
    • Company Profile

    Flame - Retardant Automotive Braided Sleeving With Abrasion Resistance

    Pet Durable Abrasion Resistance Automotive Braided Sleeving For Wire Harness


    Product feacture:


    1. Light weight & Flexible & Insulation & UV Resistant & Decoration & Flame-retardant & Durable abrasion resistance & Resistant to chemical degradation, in a wide range of industrial applications.
    2. Braided of 0.25mm / 0.2mm Pet monofilament.
    3. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
    4. Totally expanded the sleeving can reach at least one point five times than the initial dimension.
    5. Logo printing is available.
    6. Customized,Special package is willing to accepted,can be product according to customers requirements.


    Application of braided sleeving


    It's used to cover cables, wire harnesses, tubes, industrial hoses, Automotive, Automatic equipment, where is required an additional protection.


    Technical data:


    1. Material: Polyester
    2. Operating range: - 50C - +150C
    3. Melt Point: 250C+-5C
    4. Flammability: VW-1
    5. Standard colour: Black and grey. Other colors upon request.
    6. Certificate: UL, CSA, RoHS, PFOS, REACH, Halogen Free
    7. Cutting tool: Hot knife


    PET Expandable Tube is braided from polyethylene terepthalate (PET) monofilament yarns. The material has a wide operating temperature range, is resistant to chemical degradation, UV radiation, and abrasion. The sleeving cuts easily and cleanly with a hot knife and once installed, will beautify and protect any wire, hose or cable application.


    Dimensions:


    WidthExpandable rangePacking
    (m/roll)
    InchmmMin.Max.
    1/8316500
    1/4639500
    5/168516400
    3/810719400
    1/212824300
    5/8151027300
    3/4201430250
    1251835200
    1 1/4302050150
    1 1/2403060100
    1 3/4453575100
    2504080100
    2 1/26445105100
    37664120100


    Notes:


    1. Nominal size indicates the flat width.

    2. The part No. will be followed with BK, GR and so on to indicate the color of sleeving.

    3. This sleeving has expandable character, the following sizes are covered by the nearest:16mm=15mm, 19mm =20mm , 32mm =30mm , 38mm=40mm, 51mm=50mm.

    4. Special packing, sizes, and colors can be supplied upon request.

    5. All numerical data are average or typical values, not including customized sizes.
