    Sae J526 Welded Carbon Steel Pipe , Dom Round Steel Welded Pipe 1 - 12m

    Torich SAE J526 Carbon steel price per kg DOM Tube Welded Steel Tube

    Products Description:

    16X1 20X2 DIN2391 ST35 CDS DOM Steel Tube

    DIN2393 ST35 CDW DOM Steel Tube


    DOM Steel Pipe


    Steel Grade/Steel Material:

    E155,E195,E235,E275,E355


    Delivery Condition:

    BK, BKW, BKS, GBK, NBK


    Size Range:

    OD: 4.0-420mm

    WT:0.5-50mm

    Length: max 12000mm

    Our regularproduction size 60x50 42x3.2mm


    Characteristic:

    Good concentricity

    Good OD and ID tolerance

    High Precision

    Stable quality

    Smooth Roughness

    TORICH QUALITY ASSURANCE


    Production Processs:

    ERW/Seamless tube and Cold Drawing or Cold Rolling Production


    Permissible Tolerance of Outer Diameter and Wall Thickness (mm)

    Type of steel TubeDimension of steel tubePermissible tolerance
    Average classHigh class

    Hot-rolled

    (extruded and expanded) tube

    		Outer diameter DAll±1%
    (min.+/-0.50)    		-
    Wall thicknessAll+15%/-12.5%
    (min.+4.5/-4.0)    		-
    Cold-drawn (cold-rolled) tubeOuter diameter D6~10±0.2±0.15
    >10~30±0.40±0.20
    >30~50±0.45±0.30
    >50±1%±0.8%
    Wall thickness<1±0.15±0.12
    >1~3+15%
    -10%    		+12.5%
    -10%
    >3+12.5%
    -10%    		±10%
    Note: For hot-expanded tubes with outer diameter>35mm,the permissible tolerance of wall thickness is±18%.

    Longitudinal Mechanical Properties of Steel Tubes

    NO.Steel GradeTensile Strength(Mpa)Yield point(Mpa)Elongation after breaking(%)
    s<16s>16
    Not less than
    110335~47520519524
    220410~55024523520
    3Q295430~61029528522
    4Q345490~66532531521

    Permissible deviations of the product analysis from the specified limits

    ElementLimiting values for cast analysisPermissible deviatioon of the product analysis in % by mass
    C≤0.22+0.02
    Si≤0.55+0.05
    Mn≤1.60+0.10
    P≤0.025+0.005
    S≤0.015+0.003
    Al≥0.025-0.005

    007_


    Click it to know more


    1pXaJ

    12MFAQ

    Q: Are you trading company or manufacturer ?

    A: A professional steel pipes materials inventor, manufacturer and solution provider

    Q: How long is your delivery time?

    A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.

    Q: Do you provide samples of carbon steel tube ? is it free or extra ?

    A: Yes, we could offer the sample for free charge but need pay the cost of freight.

    Q: What is your terms of payment ?

    A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
    If you have another question, pls feel free to contact us
