dc motor electric piston pump 12v vacuum air piston pump for
inflate and deflate gas
Product Description
12v vacuum air piston pump's parameter and features
| Model | DH712-4302-4500 |
| Size(mm) | 43.6*87*112 |
Voltage(V/DC) | 6V/9V/12V/24V |
| Power(W) | 30 |
| Free Flow(L/M) | 20 |
| Max. vacuum(Kpa) | -80 |
| Max.pressure(Kpa) | 430 |
| Weight | 600 |
Remark: Usually our pump has 4 kinds of voltage:6V, 9V,12V and 24V.
When you choose pump, you can tell me the pump's voltage you need.
We can do it for you.
12v vacuum air piston pump's Feature
1. DC motor with long lifetime
2. Low noise
3. Continuous operation: The pump can sustain heavy duty work for a
day;
4. Compact design, It has good waterproof;
5. Low power consumption, high efficient-save on operating cost;
6. Small and Light-weight, Installation is very simple;
7. Wide application;
8. Perfect for indoor or outdoor use;
9. It can be customized according to customer's technical
requirements.
12v vacuum air piston pump's size:
Pump Size:43.6*87*112mm
Pump Weight:600g;
Outlet:OD 8.5mm, silicone hose suggestion:ID 7.5mm
Materials:pump body: PPS, membrane:Teflon , diaphragm: EPDM
Because we use imported ball bearing,the pump’s performance is
stable and high.
The membrane is made by Teflon and pump's body is made by PPS which
make pump well endurance and strong chemical resisitance.
12v vacuum air piston pump's information
Our company offers multiple component configurations allowing
piston pump to be used for either vacuum operation, pressure
operation, or alternating vacuum and pressure operations.The
innovative, compact design incorporates leading edge technologies
that allow it to operate harder, quieter and longer, reliable,
highly efficient.
Its flow can deliver up to 12 l/min and 45L/M.
Its vacuum can be -70kpa to -90kpa.
Its pressure can be 200kpa to 500kpa.
You can choose pump according to our model.
In addition,it can be mounted in any position.
12v vacuum air piston pump's application
1. breast pump
2. Beauty equipment
3. Vacuum packaging machine
4. Double-headed electric breast pump
5. Portable ozone sterilizer
6. Vacuum sealing machine
7. Beauty massage
User Instructions
1. will not guarantee the products if the application of our
products are exceeded the limitation which is specified on this
specification.
2. In case of changes of the specification specified on this
document. A written notice is requested in advance.
3. there is any data or related documentation different from this
data sheet.This data sheet is the principle reference.
4. Please do not use it in the environment of corrosive gas or
liquid or any detrimental gas. 5.While the motor is in
operation,please do not lock the motor intentionally for a long
periods,since the continuous stoppage will result in overheat and
thus burnt out the motor.
