Outdoor Corrugated Copper Tube Coaxial Cable With 3.0 KV Dielectric Strength

    Buy cheap Outdoor Corrugated Copper Tube Coaxial Cable With 3.0 KV Dielectric Strength from wholesalers

    Buy cheap Outdoor Corrugated Copper Tube Coaxial Cable With 3.0 KV Dielectric Strength from wholesalers
    • Buy cheap Outdoor Corrugated Copper Tube Coaxial Cable With 3.0 KV Dielectric Strength from wholesalers

    Outdoor Corrugated Copper Tube Coaxial Cable With 3.0 KV Dielectric Strength

    Ask Lasest Price
    Brand Name : ZD
    Model Number : RF5012Z(1/2'Z)
    Certification : CE RoHS
    Price : Negotiable
    Payment Terms : D/P, D/A, T/T, L/C, MoneyGram, Western Union
    Supply Ability : having stock
    • Product Details
    • Company Profile

    Outdoor Corrugated Copper Tube Coaxial Cable With 3.0 KV Dielectric Strength

    50Ohm corrugated 1/2" super Flexible Cable Feeder Cable Coaxial cable


    *. Tinned Copper BC: Bare Copper CCS: Copper Clad Steel CCA: Copper Clad Aluminum

    *. Al-Foil: Non-bonded Al-foil, bonded Al-foil, double bonded Al-foil, and double non-bonded

    Al-foil and Messenger are available;
    *. Braiding wire: AL, BC and TC available;
    *. Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm available;
    *. Braiding net: 32, 48, 64, 72, 80, 96, 120, 128, 144 and more available;
    *. Braiding coverage: Between 30- 97% available;
    *. PVC jacket of Flame retardant, UV, or UL available.


    1(Inner Conductor Material)

    (Copper Tube)

    2(Diameter Over Inner Conductor)≥4,8mm
    3(Dielectric Material)Foam PE
    4(Diameter Over Dielectric)≥11,9 mm
    5(Outer Conductor material)(Corrugated copper tube)
    6(Diameter Over Outer Conductor)≥13,8 mm
    7(Jacket material)PE/FRNC Halogen Free
    8(Diameter Over Jacket)≥15,8mm
    9(Weight(kg/km))≥200 mm
    10(Tensile Strength) (N)≥1100
    11(Min,Bending Radius(single)) (mm)≤ 70
    12(Min,Bending Radius(repented))(mm)≤ 127
    13(Installation Temperature (°C)0~+55
    14(Operating Temperature (°C)0~+55
    15(Impedance) (Ω)50 +/-1
    16(Relative Velocity of Propagation(%))≥88
    17(Capacitance) (pF/m)≤76
    18(Inductance)(μH/m)≤0,19
    19(Maximum Operating Frequency) (GHz)≥8
    20(Peak Power Rating) (kw)≥38
    21(Jacket Spark Test Voltage)(V)≥8000
    22(Inner Conduct DC-Resistance) (Ω/km)≤1,57
    23(Outer Conductor DC-Resistance) (Ω/km)≤2,7
    24(VSWR) (890~960MHz)≤ 1,152
    25(VSWR) (1710~2180MHz)≤ 1,152
    26(VSWR) (2500~2690MHz)≤ 1,152
    27Attenuation) (900 MHz) (dB/100m) (tính cả dung sai)≤ 7,15
    28(Attenuation) (1800 MHz) (dB/100m) (tính cả dung sai)≤ 10,41
    29(Attenuation) (2200 MHz) (dB/100m) (tính cả dung sai)≤ 11,66
    30(Attenuation) (2700 MHz) (dB/100m) (tính cả dung sai)≤ 13,1
