support full / half MDI / MDIX mini 5 ports POE fast ethernet
switch with 4 * 10 / 100M POE ports and
one uplink port
Ethernet networking
With 10BASE-T and 100BASE-TX, separate twisted pairs are used for
the two directions of communication. Since twisted pair cables are
conventionally wired pin to pin there are two different pinouts
used for the medium dependent interface. These are referred to as
MDI and MDI-X (medium dependent interface crossover). When
connecting an MDI port to an MDI-X port, a straight through cable
is used while to connect two MDI ports or two MDI-X ports, a
crossover cable must be used. Conventionally, MDI is used on end
devices while MDI-X is used on hubs and switches. Some hubs and
switches have an MDI port (often switchable) to connect to other
hubs or switches without a crossover cable.
The terminology generally refers to variants of the Ethernet over twisted pair
technology that use a female 8P8C port connection on a computer, or other network device.
The X refers to the fact that transmit wires on an MDI device must
be connected to receive wires on an MDI-X device. Straight through
cables connect pins 1 and 2 (transmit) on an MDI device to pins 1
and 2 (receive) on an MDI-X device. Similarly, pins 3 and 6 are
receive pins on an MDI device and transmit pins on an MDI-X device.
The general convention is for network hubs and switches to use the MDI-X configuration, while all other nodes
such as personal computers, workstations, servers and routers use an MDI interface. Some routers and other
devices had an uplink/normal switch to go back and forth between
MDI and MDI-X on a specific
Testing
The terminology generally refers to variants of the Ethernet over twisted pair technology that use a female 8P8C port connection on a computer, or other network device.
The X refers to the fact that transmit wires on an MDI device must
be connected to receive wires on an MDI-X device. Straight through
cables connect pins 1 and 2 (transmit) on an MDI device to pins 1
and 2 (receive) on an MDI-X device. Similarly, pins 3 and 6 are
receive pins on an MDI device and transmit pins on an MDI-X device.
The general convention is for network hubs and switches to use the MDI-X configuration, while all other nodes
such as personal computers, workstations, servers and routers use an MDI interface. Some routers and other
devices had an uplink/normal switch to go back and forth between
MDI and MDI-X on a specific port.
Mini 5 ports POE switch feature
◆Supports IEEE 802.3x flow control for Full-duplex Mode and back
pressure for Half-duplex Mode
◆1K entry MAC address table of the PoE Switch with auto-learning
and auto-aging
◆Support Extend 250meters
◆Support Fixed Vlan(Optional)
◆External power adapter supply
Plug and Play
The standards-based PoE Switch senses and adjusts for network speed
and cabling type automatically, for easy integration into your
existing 10/100 Ethernet network. For PoE, the switch automatically
detects IEEE802.3af-compliant devices, and supplies power as
needed. Front panel LEDs keep you informed of switch and PoE
status.
Quiet and Compact
Engineered for compact convenience, it durable metal case that is
easily positioned on your desktop or a wall, using the included
mounting hardware. The fan-less design quietly integrates with your
small office environment.
Flexible
Choose to plug in up to five Ethernet or Fast Ethernet devices and
mix in up to four IEEE802.3af IP-based devices like wireless access
points or IP-based network surveillance cameras. Place these
IEEE802.3af-compliant devices where they belong – high up on walls
and ceiling for maximum coverage
– or anywhere else you need them. Power and data are carried over
standard Cat 5 cabling.
Accessories in the Package:
5-Port 10/100 SWITCH with 4 POE ports and 1 Uplink Ethernet
AC Adapter
User Guide
Warranty Card
| Product Name | 5-Port AF PoE Switch with 4 PoE Ports and 1 Uplink Ethernet |
| Model | NTW- SW5P |
| Connector Type | 5x 10/100M copper cable RJ45 ports(4 PoE ports+1 Uplink) |
| Network Media | 10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or more UTP
(≤100 meter) |
| Bandwidth | 1.0Gbps (non-blocking) |
| Address Database Size | 1K |
| MTBF | 190,000 hours (about 21 years) |
| Forwarding Mode | Store-And-Forward |
| Network Protocols | IEEE 802.3i 10BASET; IEEE 802.3u 100BASETX; IEEE 802.3x Flow
Control; IEEE 802.1af DTE |
| Power via MDI; IEEE 802.3af |
| |
| | |
| LED Display | System: power supply; Every Port: connecting, PoE working status |
| Power Supply | Power input: AC100-240V 50/60Hz; (every country use a custom power
plug) |
| PoE Ports | Port 1-4 support POE |
| PoE Port Power | 15.4W for each POE port |
| | |
| PoE Standard | IEEE 802.3af |
| PoE Feature | All ports support MDI/MDIX |
| Working Environment | Operating Temperature: -20 ° ~ 50 ° C; Storage Temperature: -40 ° ~
75 ° C; |
| Operating Humidity: 10% ~ 95%, non-condensing |
| |
| | |
| Certification | CE Mark ,commercial; CE/LVD EN60950, RoHS |
| Radiation | CE mark, commercial; FCC Part 15 Class B; VCCI Class B; EN 55022
(CISPR 22), Class B |
| Transmission Distance | Data transmission distance: 100m,POE distance upto 250meters with
10M via Cat.6 or more |
| Warranty | 3 year warranty ( 1 yeas warranty for power adapter ) |
| | |
