Banquet Hall Movable Sliding Operable Walls Sound Proofing Partition Walls

Ask Lasest Price
Brand Name :	BANGE
Model Number :	85 mm wooden partition walls
Certification :	ISO9001
Price :	US Dollars 80 - 120 per square meters
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	50000 square meters per month
Delivery Time :	15-20 days

Add to Cart

Product Details
Company Profile

Banquet Hall Movable Sliding Operable Walls Sound Proofing Partition Walls

Banquet Hall Movable Sliding Operable Walls Sound Proofing Wooden Partition Walls

Wooden partition walls details

Wooden partition walls system are 2-1/4” tongue-and-groove unitized panel system. Panels are 24” wide, precision laminated, and pre-finished with vinyl, fabric or other specified finish. Panels are manufactured at various heights up to 59’. All vertical and horizontal structural members consist of extruded aluminum components, with a snap-on base made of extruded vinyl. Panels lift into floor and ceiling tracks to form a rigid, uniform wooden partition wall system that provides excellent sound transmission resistance with a STC rating of 35 to 58dB.

The BUNGE Wooden Partition Wall is aluminum-framed operable partition is the most versatile operable wall constructed today. Wooden partition walls are a series of flat panels, approximately range from 600mm(23") to 1200mm(47") wide. They have a wide array of features and options to meet most design and budget requirements. Models are acoustically rated, available in 65mm(2.6") ,80mm(3")or 100mm(4") thick models, and in single, pair hinged configurations.

The continuously hinged panels are pulled from their parked position to ‘close’ (or extend) the wall and pushed back to the parked position to ‘open’ (or fold)the wall. Final flat alignment of wall panels is assisted pneumatically by a gas piston located in the top track. A lever or recess handle is fitted to the lead panel and this combined with a vertical rebated profile provides the system with its pass door. The door is available with or without a lock cylinder.

Wooden Partition Walls Features & Benefits

Movable, top hung system without the need for a floor track

Retractable top and bottom seals ensure effortless movement of panels

Combines elegance with robust construction

Concealed or exposed panel edge profiles

Numerous panel stacking options for complete flexibility

Sealed for life roller assemblies provide smooth and silent movement

Various levels of sound reduction

Panel Suspension	Top hunge system without the need for a floor track.
Panel Width	Each panel 600mm-1200mm.
Track	Aluminum OR Steel Track
Roller on panel	Single or Double Roller
Panel Frames	Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
Top&bottm seals	Top and bottom pressure retractable seals ensure effortless moved and locked.
Module	700mm - 1200mm maximum.
Panel stacking	Numerous panel stacking options for complete flexibility.
Panel face	MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes	Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard.

How do the goods packing?

Corrugating paper packaging, MDF batten cover all around corner.
The movable wall panel and track, fittings will be packed separately.

What is Procurement procedure?

Firstly, send us the shop drawings(if the shop drawings is not available, you can tell us the height from false ceiling to finished floor and width from wall to wall)
Secondly, we offer you the movable wall layout drawings for your confirmation
Thirdly, we quote the movable wall in accordance with confirmed drawings.

What is finishing face?

The bottom panel is MDF or plywood, which is unfinished face. You can do decoration on site, such as wallpaper, paint, etc.
We can also provide the product with finished face, such as faux wood, Woven fabric and Leather.
