    Power Electrical SMT Transformer H1300NL Single Port Magnetic Modules

    power electrical Lan Transformer H1300NL Single Port Magnetic Modules


    Description:

    Size: 12.7*7.11*5.97mm

    Core No. : 2

    Pin No. : 16

    Inductance : 350 uH MIN

    Type : lan transformer

    Speed: 10/100Base-T

    Hi-pot :1500Vrms


    PARAMETERSPECIFICATIONS
    OPERATING TEMPERATURE0 - 70
    TURNS RATIO1 :1 ±2%
    POLARITYPER SCHEMTIC
    INSERTION LOSS100KHz1-125 MHz
    -1.2 dB MAX-0.2 -0.002*f ^1.4 dB MAX

    RETURN LOSS

    (Z OUT = 100 OHM ±15%)

    1-30MHz30-60HMz60-80MHz
    -16 dB MIN

    -10+20*LOG10

    (f/60 MHz) dB MIN

    -10 dB MIN

    INDUCTANCE(OCL)

    (MEDIA SIDE, 0 -70 )

    350 uH MIN(MEASUREN AT 100KHz,100mVRMS AND WITH 8mA DC BIAS)

    CROSSTALK, ADJACENT

    CHANNELS

    1MHz10-100MHz
    -50 dB MIN-50+22*LOG 10(f/10) dB MIN
    DIFFERENTIAL TO COMMON MODE REJECTION2 MHz30-200MHz
    -50 dB MIN-15+20*LOG 10(f/10) dB MIN

    DC RESISTANCE

    1/2 WINDING

    .65 OHMS MAX

    DC RESISTANCE

    IMBALANCE

    .065 OHMS MAX (CENTER TAP SYMMETRY)

    INPUT -OUTPUT

    ISOLATION

    1500 VRMS MIN @ 60 SECONDS

    power electrical Lan Transformer H1300NL Single Port Magnetic Modules


    Shape and Dimensions:

    Quality Power Electrical SMT Transformer H1300NL Single Port Magnetic Modules for sale
