| Manufacturer | NXP USA Inc. | |
|---|
| Series | LPC17xx | |
|---|
| Packaging | Tray | |
|---|
| Part Status | Active | |
|---|
| Core Processor | ARM® Cortex®-M3 | |
|---|
| Core Size | 32-Bit | |
|---|
| Speed | 120MHz | |
|---|
| Connectivity | CAN, EBI/EMI, Ethernet, I²C, Microwire, Memory Card, SPI, SSI, SSP,
UART/USART, USB OTG | |
|---|
| Peripherals | Brown-out Detect/Reset, DMA, I²S, LCD, Motor Control PWM, POR, PWM,
WDT | |
|---|
| Number of I/O | 165 | |
|---|
| Program Memory Size | 512KB (512K x 8) | |
|---|
| Program Memory Type | FLASH | |
|---|
| EEPROM Size | 4K x 8 | |
|---|
| RAM Size | 96K x 8 | |
|---|
| Voltage - Supply (Vcc/Vdd) | 2.4 V ~ 3.6 V | |
|---|
| Data Converters | A/D 8x12b, D/A 1x10b | |
|---|
| Oscillator Type | Internal | |
|---|
| Operating Temperature | -40°C ~ 85°C (TA) | |
|---|
| Package / Case | 208-LQFP | |
|---|
| Supplier Device Package | 208-LQFP (28x28) | |
|---|
| Base Part Number | LPC1788 |
|---|
