Remote Control Circuit Board PCB
It is a 2 layers remote control circuit board PCB , with 1.6 mm
board thickness . Also ,the surface treatment of this PCB is OSP
,which is solderd with green .
What We Can Do for You?
With over 18 years experience, we offer OEM & ODM PCB Layout, PCB Design, PCB manufacturing and
PCB Assembly in single-sided PCB Board, double-sided PCB and Multilayer Printed
Circuit Board service to
our customers, with total production capacity of 290,000 sqm/month.
How to get quick quotation?
| Step 1 Please send us Gerber file with these format: .CAD / .Gerber / .PCB / .DXP / .P-CAD, etc |
| Step 2 Also please provide us the below details for quick quotation: |
Board material: Fr - 4 / CEM - 1 / CEM - 3 / 22F / Fr - 1 / others |
| Material brand: SY / KB / Rogers (optional) |
| Material Specification:High Tg / copper based / aluminum based or
others (optional) |
| Board thickness: 0.1 - 6.0 mm |
| Copper thickness: 0.05 Oz - 8 Oz ( 17 um - 288 um ) |
| Surface Treatment: OSP / ENIG / HASL / Lead Free HASL / Immersion
Tin / Immersion Sin |
| Color of solder mask and silk print: Green / red / blue / black /
white / yellow ,etc |
| Board size and quantity |
If you don't have Gerber file, please provide us the imfomation as
step 2 or post your PCB Board to us for clone.
|
SAMPLE:
|
Board Basic Info - SAMPLE | Board material | Fr - 4 | Material brand | KB | Material Specification | Tg 170 | Board thickness | 1.6 mm | Copper thickness | 1 Oz | Surface Treatment | ENIG | Solder mask / sSilk print | Green / White | Board size | 100 mm * 100 mm | Quantity | 10k |
|
Why you can trust our products?
-- What LEFANG's vision is to Make Our Customer's Products Better,
so we try our best to fulfill the quality control
system andenvironmental management system. Our approved
certification are as below:
| ISO9001:2008 | ISO14001:2004 |
| ISO/TS16949:2009 | OHSAS18000 |
| UL | RoHS |
| QC080000 | CQC |
Now send us your inquiry, and you will be replied within 8 hours!
Little knowledge - Size and quantity of the PCB hole
The PCB cost of the hold drilling is mainly depended on the hole
diameter, drilling speed and error value. In the process of the PCB
Board hole drilling, it will take a higher cost when the hole is
smaller. And we suggest the hole size should be no less than
0.3mm.In addition, as for the aperture ratio, our suggestion is
between 1/6 to 1/5. Because the PCB hole will be damage if the
aperture ratio less than 1/8, which will increase the scrap rate.
In the meanwhile, the more drilling hole in the PCBs, the higher
cost will be taken place.
