Fruit Vegetalbe Tunnel Dryer Machine , Tomato Apple Grape
Dehydrator
1. Quick Details
Model Number: | KS-15A | Type: | Dryer, batch type heat pump dryer/drying chamber | Voltage: | 380 V |
Power(W): | 15 KW | Weight: | 480KG | Dimension(L*W*H): (M) | 9.8×1.2×1.6 |
Certification: | CE,ISO,SGS | Warranty: | 1 year | After-sales Service Provided: | YES
overseas service provided |
Application | commercial fruit and vegetable dryer/dehydrator machine | Heating capacity: | 35kw | Cooling capacity: | 25kw |
Dehumidification amount:: | 40L/H | productivity: | 150-1000kg | Temperature range: | 8-75℃ |
Control system: | automatic, intelligent | Heat energy: | 25% electricity/75% air source(free) | New technology: | Second waste heat recovery technology |
2. Product Description
1. Multi-usage Microwave equipment suitable for difference film or
industry.
a. food drying(herb drying, meat baking, rice, seafood, potato,
rice powder...)
b. drying paper
c. fruit drying
d. chemical drying and so on
2. Advantage of Equipment.
a. Time-saving
b. Energy-saving
c. Uniform-heating
d. clean and Health
e. Convenient and easy controlling
f. can sterilization
3. Specifications
1. Multi-usage Microwave equipment
2. Industry Microwave equipment.
3. Dehydration machine
4. Drying machine
4. Features of Fruit and Vegetable Dryer/ Dehydrator Machine
1. Energy saving & Environmental protection
Adopt close dehumidify + circulating drying type, saving operating
cost;
Without waste gas and waste heat pollution, low noise
2. Running Stable, operating easily
PLC + Touch Screen, running stable, operating easily;
Adopt PLC control, can setting different drying curve,
Suitable for drying different materials.
3. Second waste heat recovery technology (patent)
Adopt air to air heat exchanger dehumidify and recovery waste heat
at the same time, saving energy more than 40%.
4. Exact control temperature and humidity
According to different material setting different drying curve, the
heat pump dryer can control the drying chamber temperature between
10-75℃, similar nature drying.
5. During drying, the material does not craze, does not
distortions, non-discoloring, never degenerate, non-oxidize, drying
completely, with good rehydration, keep nutrient content;
6. Safe and reliable operation, automatic intelligent control,
24-hour continuous drying.
Stable operation without being influenced by weather
5. Technical Parameters
Model | Working Frequency
(MHZ) | Output power
(kw) | Microwave leakage
| External Dimension Adjustable(M) | Productivity of Drying
(kg/h) | productivity of Sterilization
(kg/h) |
KS—15A | 2450±50 | 15 | ≤5 | 9.8×1.2×1.6 | 40-75 | 150-180 |
KS—20A | 2450±50 | 20 | ≤5 | 12.4×1.2×1.6 | 50-120 | 200-250 |
KS—30A | 2450±50 | 30 | ≤5 | 14.6×1.2×1.6 | 65-160 | 300-400 |
KS—50A | 2450±50 | 50 | ≤5 | 20.5×1.2×1.6 | 120-200 | 500-600 |
KS—80A | 2450±50 | 50—80 | ≤5 | 30×1.2×1.6 | 200-300 | 600-1000 |
Our services
Installation:
1. We provide videos and instruction manual to show the process of
installation.
2. We provide training for installation for free in our factory.
3. We can send technician to buyer's factory to install the machine
and provide training service.
After Sales Service:
1. One year quality warranty and free lifetime technique support.
2. Free spare parts would be supplied if machine broken within
warranty period except the easily damaged
parts.
3. After the warranty period, the spare parts for replacement are
offered based on certain charge.
