Vacuum Emulsion Mixer Machine / High Speed Cosmetic Mixer Equipment
Vacuum Emulsion Mixer Machine as a semi solid equipment are
suitable for the pharmaceutical & cosmetic industries for making
cream, ointment, lotion, soft gel, toothpaste, hair color.
Vacuum Emulsion Mixer Machine is a coaxial and triple type mixer,
suitable to stable homogenizing and emulsifying. Relying on mixing
of reversed impeller, under the condition of homogenizing turbine
and vacuum status, you can get the high-quality effect of
emulsifying and mixing.
Vacuum emulsifying mixer has very good performance in the aspect of
insuring high quality of the finished material.
Structure of Vacuum Emulsion Mixer Machine
With 3-layer structure, upper and lower end sockets. The upper end
socket is connected to the tank body with flange between them. The
internal layer of tank body is made of 4 mm thick SUS316L stainless
steel and interior polished in 300 MESH (sanitary level). The
middle layer of tank body is made of 3 mm thick SUS304 stainless
steel and can stand max. working pressure 0.09 MPa. The external
layer of tank body is made of 2 mm thick SUS304, and exterior
polished in 300 MESH (sanitary level). All the welding seams shall
be polished after rubdown, and as to the treatment interface,
turned over edge arc transition is adopted. There is a group of
heating resistor (stainless steel )with 2Kw in the jacket. The heat
preservation layer is made of PU polyurethane foaming.
Specification of Vacuum Emulsion Mixer Machine
Dimension:1400mm×600mm×1900~2400 mm
Using life: More than 15 years
Spare parts: One year spare parts and tools
Guarantee: One year
Heating method: Jacket electrical heating/Seam Heating
Exhaust method: Electric doom and bottom discharge or positive
pressure discharge material
Control box: SUS304 , 1.2mm thickness
In the tank, there are 3 mixers:
1 Cutting and vortex emulsify mixer: 7.5kw, 0-3500 rpm (frequency
control)
2 Low-speed frame type scraping mixer: 2.2kw, 0-40 rpm (frequency
control)
3 The motor of Low-speed converse mixer and low-speed frame type
scraping mixer is the same one with speed 0-40rpm.
| Product Name: | Emulsion Mixer Machine | Heating Type: | Electrical Heating Or Steam Heating |
|---|
| Weight: | 3460kgs | Voltage: | 220V/380V, 50Hz/60Hz |
|---|
| Application: | Pharmaceutical & Cosmetic Industries | Material: | SS316L And SS304 |
|---|
| Capacity: | Customized | Vacuum Pump: | Water Ring Type |
|---|
