| Brand Name : | Iflow |
| Model Number : | LXSG15 |
| Certification : | ISO 4064, GB/T19001 |
| Price : | negotiable |
| Payment Terms : | T/T, L/C, D/P |
| Supply Ability : | 2200000 unit per year |
| Delivery Time : | 4-6 weeks |
Multi jet water meter , dry dial, DN15 brass body for water utility
volumetric flow ISO4064
Description
The dry dial water meters use the multi-jet principle, also single
jet principle available for smaller port size. This vane wheel
water meter is known for its wide range, simple operation, and
accuracy in cold water or hot water totalization and flow rate
metering. The impeller is centered in a ring of jets, with inlet
jets on one level and outlet jets on another. A gear train drives
the register totalizer dials.
Functions:
To record the total water volumetric flow meter in cubic, liter
which pass through the closed pipe line, like water utilities,
municipal water supply, etc.
Features
Data sheet
| Description | Unit | Hydraulic data and dimensions | ||
| Nominal size | mm(inch) | DN15 (1/2") | DN20(3/4") | |
| Overload flow rate (Qs) | m3/h | 2 | 3 | |
| Permeanent flow rate (Qp) | m3/h | 1 | 1.5 | |
| Transitional flow rate (Qt) | l/h | 80 | 120 | |
| Minimum flow rate (Qmin) | l/h | 20 | 30 | |
| Min reading | l | 0.05 | 0.05 | |
| Max reading | l | 99999.9999 | 99999.9999 | |
| Max work pressure | MPa | 1.6 | 1.6 | |
| Pressure difference at Qs | Mpa | <0.1 | <0.1 | |
| L | mm | 165 | 190 | |
| I | mm | 245 | 290 | |
| H | mm | 135 | 135 | |
| h | mm | 36.5 | 36.5 | |
| B | mm | 94 | 94 | |
| D | inch | G3/4B | G1B | |
| d | inch | R1/2 | R3/4 | |
| weight | with connections | kg | 1.49 | 1.75 |
| without connections | 1.29 | 1.45 | ||
Flow curve
Pressure curve
Competitive Advantage:
Production line
Pallet pack
|
