Tungsten Calcining Rotary Tube Furnace Energy Saving With Adjustable Tilting Angle

    Buy cheap Tungsten Calcining Rotary Tube Furnace Energy Saving With Adjustable Tilting Angle from wholesalers

    Buy cheap Tungsten Calcining Rotary Tube Furnace Energy Saving With Adjustable Tilting Angle from wholesalers
    • Buy cheap Tungsten Calcining Rotary Tube Furnace Energy Saving With Adjustable Tilting Angle from wholesalers

    Tungsten Calcining Rotary Tube Furnace Energy Saving With Adjustable Tilting Angle

    Ask Lasest Price
    Brand Name : EasyFashion
    Model Number : GN8000C
    Certification : ISO9001:2008
    Price : To be discussed
    Payment Terms : T/T, Western Union
    Supply Ability : 15~25 sets per year
    Delivery Time : 120~160 days
    • Product Details
    • Company Profile

    Tungsten Calcining Rotary Tube Furnace Energy Saving With Adjustable Tilting Angle

    Tungsten Rotary-tube Calcining Furnace Rotary Tube Furnace Energy Saving


    Overview:

    The equipment is mainly used for calcining of chemical and metal powders. For example, it can calcine APT to get WO3.


    Suitable for tungstate ammonia and ammonium molybdate. Specialized for tungsten and molybdenum metallurgy industry.


    Technical specifications:

    ModelGN5800CGN6300CGN8000C
    Size(mm)Φ300×5800Φ400×6800Φ400×8000
    Power90kW140kW300kW
    Rated voltage380V 50Hz, three-phase five-wire
    Rotating speed of tube1~8 r/min
    Temperature controlThree zonesFour zonesFour zones
    Tilting angle of tube3°~6° adjustable
    Max. working temperature(°C)700°C
    Max. testing temperature(°C)900°C
    Powder recycling rate≥95%
    Dimension(L×W×H)8100×1400×2750mm

    10000×1780×3280

    mm

    10500×1800×2890mm

    Features:
    1. The charging and discharging spirals of furnace tube adopt conversion frequency to control output and quality.
    2. Stable temperature change, precision control, less error, high quality.
    3. Suitable for different products and quality.
    4. Energy saving, long service life, high production efficiency.

    Quality Tungsten Calcining Rotary Tube Furnace Energy Saving With Adjustable Tilting Angle for sale
