96 Cores Outdoor FTTH Fiber Optic Cable Junction Box with Reinforced SC Connector

96 Cores Outdoor FTTH Fiber Optic Cable Junction Box with Reinforced SC Connector

This fiber optic splitter box is able to hold up to 8pcs reinforced adapters. It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system. Its splice trays are jointed with a hinge at one side, which makes the operation in each tray easier. You can take each tray out, after splice, then fix it in closure. The box integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.

Features

• Water-proof design with IP-65 Protection level.
• Integrated with flap-up splice cassette and adapter holder.
• 96F splice capacity and 8 positions for SC reinforced adapters.
• Plug-and-play installation, easy for maintenance and expansion.
• Fiber bend radius control more than 40mm.
• 180 degree access with buckled lock structure.
• 1*8 PLC splitter can be installed in each splice tray as option.
• 8 pcs of pre-installed reinforced water-proof adapter for SC.
• 1 uncut cable port(10-16.5mm) for uncut cable and 2 reserved cable entrance for distribution cable(8-16.5mm).

Specification

More Detail

Outer of box Inside of box

• There are total of 4pcs splice tray that can splice 24 fibers for each tray.
• Picture 2, A black strap fixes all splice trays to avoid damage.

The bottom of box Cover

• Picture 1 shows the inside of splice tray, each splice tray can splice 24 fibers max. There is a groove to put steel tube of mini PLC splitter.
• Picture 2 shows the cover of splice tray, there is a tool on the cover. we can use the tool to coil and storage fibers.

Inside of the mini optiTap connector Outer of the mini optiTap connector

• Can use the black dust cap to block the ports if do not use the outports. The black cap is waterproof.

• On both sides of the uncut port, there are 2 reserved cable entrance. As the red circle marked.
• Can install the cable gland(picture 2) on the reserved cable entrance.

• Shows the cover of box, this box is sealed by screw and buckle.
• As the above picture, there is a laser mark on the middle of the cover

• The metal parts are the wall mounted accessories. We install the metal parts on the back of box (as the red marked).
• If need pole mount kits, please tell us.

Accessories Packing box

Standard Accessories

Pole mounted kits, Aerial hanging kits.
