105-300 Model Knitted Wire Mesh
Knitted wire mesh(also known as knit wire or knitted wire) is a
highly adaptable and configurable material offering superior
functionality in a variety of applications. Knitted in a circular
pattern resembling a tube sock, its interlocking-loop construction
gives it tremendous strength and resiliency while allowing it to be
pliable and to conform to almost any size, shape or density
requirements. Because it can be made from any metal, plastic or
fiberglass thread or wire, its physical characteristics can be
tailored and tweaked to meet any operating environment
requirements.
Monel knitted wire mesh has good corrosion resistance in all
extreme environments and it is reasonably conductive and is tough
with high tensile strength, giving good wear characteristics.
Knitted wire mesh made of tinned copper clad steel has the best
shielding performance of all wires used in knitted meshes,
combining low contact resistance with a small degree of
permeability. It is not suitable for highly abrasive applications
where the TIN plating may wear away to expose the copper. The
corrosion resistance of tinned copper clad steel knitted wire mesh
is suitable for most applications
Aluminum knitted wire mesh is mechanically weak and will readily
take a compression set and this combined with its readiness to form
a non-conducting oxide.
Materials:
Stainless steel: 304, 304L, 316, 316L
Carbon steel : Q195, Q235, Q275
Brass: CuZn40, CuZn37, CuZn35, CuZn30, CuZn20, CuZn5
Copper: C10200, C11000
Aluminum: 1050, 1060, 1100, 5052, 5056, 5083
Nickel: N2, N4, N6, Cr20Ni80, Monel400, Monel600
Brass WireFeatures:
Low pressure drop;
High collection efficiency;
Fast delivery and service;
Custom-designed for specific applications;
Efficient and economical for a wide range of applications;
Porous blankets of knitted metal or plastic wire mesh;
It is convenient for installation, operation and maintenance.
Applications:
Insulation or hot side support material that is flexible, removable
and reusable to with stand extreme temperatures or corrosive
environments;
Insulation or filtration as an alternative to steel wool where
loose fibers or fallout is a concern;
Oil Mist Separation, mist eliminators or Demister pads for oil &
gas, utilities and commercial kitchen exhaust systems;
Sound Attenuation filter in pneumatic tools and vacuum;
Cryogenic gaskets, seals & discs;
Automotive exhaust air gap spacers, flex joint seals and air bag
filters;
Pre-filter for coarse dust in the heating and ventilation systems;
Gas turbine and compressed air inlet / outlet filter;
Engine exhaust muffler packing;
EMI / RFI Shielding;
Specifications:
| Model | Material | Wire Diameter | Mesh Width | Mesh Length |
| 105-300 | Stainless Steel | 0.1-0.3mm | 10-1600mm | 10-100m |
| Carbon Steel | 0.1-0.3mm | 50-500mm | 10-100m |
| Copper Brass | 0.1-0.3mm | 100-500mm | 10-100m |
| Aluminum | 0.1-0.3mm | 10-1600mm | 10-100m |
| Nickel | 0.1-0.3mm | 100-600mm | 10-100m |
Notes:
1. 105-300 model: it has 105 openings in the mesh width of 300mm.
2. Common wire diameter includes 0.20mm, 0.23mm, 0.25mm, 0.28mm.
3. The mesh can be made into single strand, double strand,
multi-strand etc.
4. The surface include flattened and crimped. |
Packing: Knitted wire mesh is packed in rolls or plastic spools ,wrapped in
moisture-proof paper or plastic film, sutside wooden cases or
wooden pallet.
