Vehicle Mounted Convoy Bomb Jammer Car Remote Jam 20MHz To 6G
Frequency
Description:
SA-VIP800 is a High Power DDS Convoy Jamming System, implementing
the most effective and reliable RF jamming technology and equipped
with a fully-integrated broadband jamming system.
1. Designed with ultra broadband frequency bands, 20MHz- 6000MHz
2. 12 modules plug and play design, facilitate for future power
upgrading, change and maintenance. Any ruin on the modules never
interfere the normal operating of other modules.
3. American Mil-spec standard case, shockproof and drop-resistance,
available for the vehicle running in a worse field environment.
4. Up to 20 Frequency Bands. All Jamming Modules Designed by DDS
technology.
5. Operators are able to regulate the working frequency band and
output power of each module through the software. Configuring a
specific frequency band can ensure the internal communication in
emergency.
6. System operation can be performed in the driver's console unit.
Each module can be ON/OFF. Backup
battery or generator system can be optional.
7. Continuously and simultaneously interference to the common used
RF signals.
8. Equipped with high power generator to ensure excellent low noise
operational capabilities.
9. Integrated backup battery system for continuous silent operation
and fast start.
10. Integrated smart active cooling system to make sure the device
working continuously.
11. Antenna is installed with a covert design.
12. Video camera with LCD monitor both inside and outside the
vehicle provide rear viewing and monitoring
Features
Using DDS Jamming technology to make the Frequency setting more
precise
High efficient output power, long jamming radius
Slow start up design of circuit to make the device work stably.
Perfect Self Protection, Over Heat protection, Over current
protection, High input Voltage and low Voltage protection, VSWR
protection
Easy operation, using Wire Control Panel to monitor the system
Integrated backup battery can support the Jammer to work one hour
Applications
1. Military Convoy
2. VIP Protection
3. RIOT Control
4. S.W.A.T Team
5. EOD Operations
6. Electronic countermeasure, etc
Power Amplifier Protection
A. Over Heat protection Thermal protector
B. Over current protection
C. High input Voltage and low Voltage protection
D. VSWR protection: against antenna miss-match including open and
short circuit
Remote Control
Wire Control Panel available
A. Output power LCD Indication
B. Output power adjusting by LCD
C. Output power on/off per band
D. Jamming frequency setting by LCD Panel
Specifications:
| Output Band | Frequency | Output power | Jamming range |
| Channel 1 | 20-80MHz | 100 Watts | 5-500 meters |
| Channel 2 | 80-200MHz | 100 Watts | 5-500 meters |
| Channel 3 | 200-500MHz | 100 Watts | 5-500 meters |
| Channel 4 | 500-1000MHz | 100 Watts | 5-500 meters |
| Channel 5 | 1000-1500MHz | 100 Watts | 5-500 meters |
| Channel 6 | 1500-2000MHz | 100 Watts | 5-500 meters |
| Channel 7 | 2000-2500MHz | 100 Watts | 5-500 meters |
| Channel 8 | 2500-3000MHz | 100 Watts | 5-500 meters |
| Channel 9 | 870-880MHz | 100 Watts | 5-500 meters |
| Channel 10 | 935-960MHz | 100 Watts | 5-500 meters |
| Channel 11 | 1805-1920MHz | 100 Watts | 5-500 meters |
| Channel 12 | 2010-2125MHz | 100 Watts | 5-500 meters |
| Channel 13 | 2110-2155MHz | 100 Watts | 5-500 meters |
| Channel 14 | 3000-4000MHz | 25 Watts | 5-300 meters |
| Channel 15 | 4000-5000MHz | 25 Watts | 5-300 meters |
| Channel 16 | 5000-6000MHz | 25 Watts | 5-300 meters |
| Optional | Frequency of each band can be customized RF out put power can be custmized |
| Warranty | One year from delivery date |
| Power supply | 50 to 60Hz, 100 to 240V AC, With AC adapter |
| Packing list | Mainframe*1, Antenna*1, Power supply*1, Control panel*1 |
