    Professional Small Hydraulic Motor BMP 160 Orbit Hydraulic Motor CE Approved

    Ask Lasest Price
    Brand Name : Hanjiu
    Model Number : BMP 160
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union,Paypal .
    Supply Ability : 100,000 units / Year
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    Professional Small Hydraulic Motor BMP 160 Orbit Hydraulic Motor CE Approved

    Hydraulic Orbit Motor BMP 160 For Mowers Harvesting equipment


    BMP series motor are small volume, economical type, which is designed with shaft distribution flow, which adapt the Gerotor gear set design and provide compact volume, high power and low weigth.



    Characteristic Features:


    * Orbital hydraulic motors BMP are medium size motors which have compact and light construction.
    * Shaft seal can bear high pressure of motor of which can be used in parallel or series.
    * Advanced construction design, high power and low weight.


    Main Specifications:


    Technical data for BMP with 31.75 and 32 shaftt:
    TypeBMP
    BMPH
    36
    BMP
    BMPH
    50
    BMP
    BMPH
    80
    BMP
    BMPH
    100
    BMP
    BMPH
    125
    BMP
    BMPH
    160
    BMP
    BMPH
    200
    BMP
    BMPH
    250
    BMP
    BMPH
    315
    BMP
    BMPH
    400
    BMP
    BMPH
    500
    Geometric displacement (cm3 /rev.)3651.777.796.2120.2157.2194.5240.3314.5389.5486.5
    Max. speed (rpm)cont.15001150770615490383310250192155120
    int.16501450960770615475385310240190150
    Max. torque (N·m)cont.55100146182236302360460475490430
    int.76128186227290370440570555580560
    peak96148218264360434540670840840780
    Max. output (kW)cont.81010111010108.5766
    int.11.512121312121210.58.577
    Max. pressure drop (MPa)cont.12.514141414141414129.57
    int.16.517.517.517.517.517.517.517.51411.59
    peak22.522.522.522.522.522.522.522.522.51813
    Max. flow (L/min)cont.5560606060606060606060
    int.6075757575757575757575
    Weight (kg)5.665.75.966.26.476.97.48

    * Continuous pressure : Max. value of operating motor continuously.
    * Intermittent pressure : Max. value of operating motor in 6 seconds per minute.
    * Peak pressure:Max. value of operating motor in 0.6 second per minute.



    MOTOR CROSS REFERENCE TABLE
    HANJIU
    HYDRAULIC
    M+S
    HYDRAULIC
    EATON
    CHAR LYNN
    ROSS
    TRW
    WHITE
    CROSS
    PARKERSAM
    BREVINI
    BOSCH
    RECROTH
    BMMMM MLHKJ SERIESOMMBGMMGX
    BMP/BM1MP HPH SERIESOMP DHMF MGWP RSTC TE TBBGMGP GXP
    BMR/BM2MR HR MLHRW,RWS,T SERIES W SERIESOMR DS OMEWMBWR RETFBRMGR GMR
    BMH/BM4MH MLHH HW HWFOMHMERETG
    BMS/BM5MS MSY MLHS2000 SERIESOMSMERETGHPRMGS GMS
    BMT/BM6MT MLHT MTM6000 SERIESOMT TMTMJHTMGT,GMT
    BMVMV MLHV10000 SERIESOMV

    MGV GMV


    Applications :


    Skid-steer attachments Swing motors Brush cutters

    Mowers Harvesting equipment

    Directional boring Winch Auger .
