Industrial Application Water Treatment System / Water Purifying
Machine
Specification
This water treatment system / water purifying machine is used for
producing high quality water for juice,
CSD,etc.
It adopts PLC control
Steady capacity: 1-20T/H
Detailed Information
One-stage reverse osmosis water treatment process
Original water(tap water, surface water,underground water) pass
pretreatment ,sophisticated filter,and
then sent to reverse osmosis by high pressure pump to produce pure
water directly that is known as one-
stage reverse osmosis.
One-stage reverse osmosis is suitable for the original water with
conductivity less than 500 us/cm and
conductivity of output water is 1-10 us/cm.
Two-stage osmosis pure water treatment process
The original water(tap water,surface water, underground water) is
sent to pretreatment system
by adding pressure to be filtered roughly, then to be filtered by
sophisticated filter,after that
the water is transmitted to primary reverse osmosis by one-stage
high pressure pump to be
filtered, then the water is added pressure again by secondary high
pressure pump and sent to
second reverse osmosis system to produce the product water, that is
called two-stage reverse
osmosis.
Original water conductivity>500us/cm,purified water
conductivity:1-10us/cm
Ultra Filtration Mineral Water Treatment Process
Normally the ultrafiltration is used to produce mineral water and
spring water. Driven by
pressure,it is a process of discharging impurity through different
diameter hole on the
ultrafiltration membrane. At present, the hollow-fiber type of
polysulfones are widely used in
water treatment industry.
Main parameter
| Model | Raw water conductivity | Purified water conductivity |
| One-stage reverse osmosis | less than 500us/cm | 1-10us/cm |
| Two-stage reverse osmosis | more than 500us/cm | 1-10us/cm |
We offer professional turnkey project from design till done of the
whole project.
1.Project consultation
2.Design
3.Factory building
4.Installation
5.Commissioning
6.Training
