Introduction
The DCH30 series laser position paper box cutting machine is
developed from the product of DCH10 series Apart from the functions
same with that of DCH10, this range of paper box cutting equipment
is also designed with the function of laser positioning, making the
product particularly suitable for cutting the printed PVC board and
cardboard. Accurate positioning is realized through perfect
matching between the laser and the preprinted mark on the printed
material This laser position paper box cutting machine is
distinguished by high accuracy and simple operation. In addition to
cost saving for cutting mould, this paper box cutter supports
convenient adjustment and fast speed, helping user to win orders
easily. This product also called box sample maker, PVC box sample
maker, sample maker, Ads cutting machine and so on, according to
the different cutting material and application.
Application:
Packaging, Graphic, Ads.
Cutting materials:
card paper, foam, thin PVC, grey board etc.
Main Features
Dual tool head: press roll and special knife
It supports material cutting and creasing at one stroke.
Low maintenance cost
Simple operation, accurate positioning
Specifications
| Model | DCH300906 | DCH301209 | DCH301512 |
| Effective cutting area | 900*600mm | 1200*900mm | 1500*1200mm |
| Driver | Step motor |
| Configuration | Pen, special knife, creasing tool, laser position |
| Way of fixing paper way | Vacuum absorbing |
| Driving material | Import steel belt |
| Cut materials | Red hard paper,plastic board,white board,kraft paper,thin PVC |
| Cutting way | Drawing by pen,half cutting,whole cutting |
| Cutting thickness | 0.5-2mm |
| Cutting precision | ≤0.1mm |
| Max speed | 1000mm/s |
| Working time and character | Continuous work, operating computer and cutting at the same time,
linear high-speed transmission for data. |
| Transmitting port | International standards: parallel port/RSC232 serial port |
| Instruction set | International standards: HP-GL or DXF format can be selected, |
| Numerical control board | LTD, all-English operating menu |
| Voltage | AC 220V±10% 50Hz |
| Fuse standard | 5A |
| Occupy dimension(L*W*H) | 1335*1065*1080mm | 1635*1365*1080mm | 1935*1665*1080mm |
| Note | Other size can be customized. |
Features:
The application of an English port makes Digital Pattern Cutting
Solution fast and convenient.
High performance is guaranteed with the integrated circuit plate.
The linear guide of Digital Pattern Cutting Solution ensures high
speed and few errors.
Digital Pattern Cutting Solution feature imported digital servo
drivers and their SD cards offer mass storage.
The powerful compatible function enables connection with any kind
of CAD software.
Digital Pattern Cutting Solution have an LCD touch screen in both
English and Chinese.
Digital Pattern Cutting Solution feature intellective order
printing.
