Allen Bradley Modules 2098-DSD-020X 2098 DSD 020X Servo Drive
Product Description:
Two serial connectors to simplify RS-485 multi-dropping and host
communications Several analog or digital command interfaces:
Indexing (absolute with the Homing feature, incremental, or
registration)10 Volt analog interface—position, velocity, or torque
control Presets (from one to eight binary inputs)—torque or
velocity control Quadrature encoder digital interface—electronic
gearing position follower Step/Direction digital interface—position
control CW/CCW (step up/step down) interfaceposition control
Operating mode override—alternate movement interface Host command
digital interface The ULTRA 100/200 drives host command protocol
provides optional drive configuration using the drive serial
communications interface. This powerful feature allows your
controller to access all of the drive digital controls using
sequences of ASCII characters. The protocol includes error checking
to
ensure the integrity of the transmitted commands. In installations
that have multiple axes, up to 32 ULTRA 100/200 drives can be
addressed by a host computer. These drives communicate with the
host
computer using a four-wire RS-485 serial interface. The host
command protocol includes specific drive addressing, which allows
the host to communicate with all the connected drives concurrently.
