free samples90C over load motor thermal protector thermal cut off 250V/5A 50--180C UL VDE RoHS

15AM series motor protection applications:
● Ballast
● fluorescent
● Motor
● Transformers
● laminator
● Rechargeable battery
● Solenoid
● Appliances
● PCB board
15AM series motor protector Features:
● simple design structure Minato
● can simultaneously sensing temperature and current
● Fast and accurate motion
● according to customer's requirements riveting all kinds of lead
● riveting can be divided into the same wire to the terminal to the two kinds with different
15AM series motor protector Specifications:
● function: single-hop features, automatically disconnect the circuit temperature
● Rated voltage 22A/125V 10A/250V 20A/16VDC
● Operating temperature range 50-180 ℃
● Operating temperature tolerance ± 2 ℃ ± 3 ℃ ± 5 ℃
● the number of operations ≥ 10000 times

15AM series motor protection device rated action temperature table

Description: 17AMKP and TP-D is the same type of product, reset the temperature of the standard action temperature 2 / 3, a tolerance of ± 15 ℃, or specified by the user.
