25 Tubes High Efficiency Colored Steel Vacuum Tube Solar Collector
with Feeding Tank for House
Specifications
Glass Tube Solar Collector
1.OEM available
2.Economical and efficient collector
3.For large quantity solar heating system
Technical Parameters of Glass Tube Solar Collector
| Vacuum tube | Spec.(mm) | Φ47×1500 Φ58×1800 |
| Tube (pcs) | 40 / 50 / 60 / 70 |
| Material | 3.3 Borosilicate glass, magnetron spluttering coating |
| Coating | AL/AL-ALN(H)/AL-ALN(L)/ALN or Cu/SS-ALN(H)/SS-ALN(L)/ALN |
| Manifold | Dimension | 180*160mm, 1.0 inch inlet & outlet |
| Inner tank | Food-grade SUS304-2B stainless steel |
| Tank shell | Imported color steel / Fluorocarbon (PVDF) plate |
| Insulation | High-density polyurethane integrated foam-forming layer |
| Bracket | Hot-dip galvanized steel plate (powder coating or paint baking) |
| Accessories | Stainless bolts & nuts, waterproof silicon rubber seal, dustproof rubber seal, plastic tube holder |
| Working pressure | ≤ 1 bar |
| Tilt angle | 0~ 90° |
| Hail resistance | Φ25mm diameter |
Glass Tube Solar Collector Features description:
The glass tube solar collector (non pressurized) consists of glass
vacuum tube, non pressurized manifold and supporting bracket.
Working principle
It is thermosyphon the same as integrated non-pressurized system,
water is heated directly in glass tubes.
taking advantage of the natural circulation due to smaller density
in hot water than cold water. series or/and parallel arrays of
solar collector is usually adopted for large-scale hot water
heating project.
1. Especially designed for large-scale hot water heating system,
supplying hot water for dormitories, hotels, restaurants, schools,
hospitals, factories, swimming pools, and some other sites
requiring hot water use or house heating.
2. All-glass vacuum tube, most economical and good performance at
the same time
3. Processed color steel shell and galvanized bracket make it a
long lifespan as vacuum tubes
4. Easy installation and connection and little maintenance needed
Non-pressure solar collector application
1. Hotels, resorts, hospitals and hostels
2. Process industry, boiler feed, laundry and canteens
3. Agricultural sector, hatcheries and dairies
4. Process industry, Boiler feed, Laundry and canteens
5. Agricultural sector, hatcheries, and dairies
6. Swimming pool heating
7. In-process heating
8. Health clubs (Steam / Sauna)
Warranty:
6 years international responsibility for integrated collector
exchange and 15 years for glass vacuum tube compensation due to
original quality problems.
Remark:
1. The above price is based on FOB China seaport.
2. If you only need the sample,you should add some price,it
includes the wood packing fee, transporting fee and the B/L posting
fee etc.
3. We can also put the logo of your company onto the tube or tank
as you requested, and also make different kind of colors for the
system.
4. Price validity: 15 days. Minimum Quantity: 10 units.Packing:
Export carton.
5. Payment terms: 30% T/T in advance, balance 70% T/T before
shipment.
6. Delivery time: 15 days after the date the 30% T/T payment is
received.
7. Guarantee: complete system 5 years(all accessories for 1 year).
We take all the losses caused by the quality of the goods specified
in the agreement not in accordance with the terms. We take no
responsibility for force majeure and improper operation and
maintenance from man-made.
