CE Certifited Aluminum Alloy Reflector Rock Wool U Pipe Solar
Collector 30 Tubes
Specifications
Aluminum alloy series U pipe solar collector
1. CE,ISO
2. Work pressure: 0.6MPa
3. Tube size: 58*1800mm
4. Tube Qty.: 24
Key Features
• Internationally certified product
• Reliable, efficient, twin-glass evacuated tubes
• Average 25% more energy output than flat plate collectors
• Copper heat pipes for rapid heat transfer
• 3/4" copper head connections
• Corrosion resistant silver brazed copper header with only four
braze points
• Recycled glass wool manifold insulation
• Low heat loss
• Efficient performance at high differential temperatures
• Easy plug-in installation
• Maintenance Free
• Cyclone rated frame options available
• Suitable for mains pressure water (up to 8 bar/116psi)
• Option of all stainless steel frame (439 grade SS), or high
strength anodized aluminum
• Anodized aluminum manifold casing
• Environmentally friendly manufacturing process.
| Manifold material and thickness | A, Aluminum alloy , thickness 2.0mm
B, Stainless steel 304 2B, thickness 0.8mm |
| Header pipe material and thickness | Diameter:32mm, thickness 1.0mm copper pipe |
| Heat pipe material and thickness | Diameter:14mm, thickness 0.5mm copper pipe |
| Insulation | Polyurethane 50mm or rock wool |
| Test pressure and work pressure | 8Bar, normal work pressure 6bar to 8bar |
| Frame material and thickness | A, Aluminum alloy , thickness 2.0mm
B, Stainless steel, thickness 1.2mm |
| Collector mounting | Flat roof/inclined roof |
| Inlet and outlet | 1/2'' OR 3/4'' |
| Hail resistance: | 25mm |
| Coating of vacuum tube: | SS-C/CU |
Features:
1. U pipe solar collector composes of metal U pipe, metal slice,
insulation layer, vacuum tub and collector frame.
2. water circulates due to water temperature difference between the
two sides of U pipe.
3. Solar collector is separated with tank by transmitter inside U
pipe
4. Solar radiation converted into heat energy in the water tank by
heat exchanger.
Remark
Manifold Connections(inch):3/4
Max.service temperature: 95°C
Max.stagnation temperature:200.3°C
Flow range recommendation(50-150L/m2h)
Packing and shipping:
MOQ: 20'GP container (Sample is available)
Warranty: 10 years guarantee for whole set solar water heater
Payment term: 30% deposit by TT, Balance for BL by TT or LC
Delivery time: 7 days after confirmed
Port of departure: Shanghai or Ningbo
Supply ability: 8000 sets per month
Package: Standard export cartons
Payment term:
1. T/T 30% Deposit in advance and balance should be paid after
receiving the B/L copy.
2. L/C at sight (if your quantity reaches 5*40’ HQ container)
3. Sample order or LCL: we accept western union and one touch
business.
Pre-sale Service
1.Sample can be offered with sample charge and courier fee by buy's
side
2. OEM is accepted.
3.Competitive price with good quakity
4. Experience work team
After you choice
1. we will count the cheapest shipping cost
2.check quantity quickly
After-sale Service
1. If any question, please contact with us freely by E-mail or
Telephone.
