High Absorption Blue Titanium Flat Plate Solar Collector Aluminum
Full Plate for House
Specifications
OEM offer
flat plate solar collector
Pressurized design
Advanced coating technology
100% recyclable materials
Flat-plate collector is one of common solar collectors for solar
water-heating system in homes and solar space heating.
Flat plate solar collectors provide quality hot water with its new
solar energy efficient flat plate design.
This glazed collector includes a selective coating to maximize the
solar heat absorption, weather resistant aluminum framing and
interior fiberglass insulation for increased efficiency.
Feature of Flat Plate collector
1. Using patent advanced coating technology with high efficiency
performance.
2. High strength aluminum-alloy structure with surface varnish
baking.
3. High visual shape, easy installation, maintenance free.
4. Pressurized designing, operate with pressure up to 1 MPa.
5. Can be combined with existing energy.
Specification
| Flat Plate Solar Collector |
| cover | |
| material | Tempered textured glass |
| Cover thickness | 4mm |
| Cover transmission | 87% |
| Ext dimension | 2000 ×1060× 75/82/95mm |
| Aperture area | 2m2 |
| Absorber |
| Dimension L*W*T | 1840*980*0.15 |
| material | Red copper |
| Surface coating | Black chromed/blue sputtered |
| Construction type | Fin&tube(ultrasonic welding) |
| Header mterial | Copper T2 |
| Heater tuber size(L*W*L) | 1060mm*25mm×0.62pcs |
| riser material | Copper T2 |
| Rise tuber size(L*W*L) | 1886mm* 10mm*0.458pcs |
| Absorptivity | a=0.93(±0.05) |
| emittance | a=0.93(±0.05) |
| Thermal insulation |
| Insulation material | Fiber glass insulation(black backing) |
| Insulation thickness | Back 25mm |
| Conductivity(w/mk) | ≤0.048w/m.k under test temperature 70°C |
| Other parameters |
| frame | Aluminum alloy |
| Back plate | Galvanized steel plate 0.3mm |
| Max operation temperature | 200°C |
| Maximum pressure | 1400kpa |
| Sealing gasket | EPDM |
| Max working temperature | 120°C |
| Max working pressure | 10bar |
| Daily output volume | 105~300L |
Warranty
10 years international responsibility for Flat Plate Panel Solar
Collector due to original quality problems.
Basic trade term & packages
MOQ: 20'GP container (Sample is available)
Warranty: 10 years guarantee for whole set solar water heater
Payment term: 30% deposit by TT, Balance for BL by TT or LC
Delivery time: 7-15 days after confirmed
Port of departure: Shanghai or Ningbo
Supply ability: 8000 sets per month
Package: Standard export cartons
Packaging & Shipping
Packaging Details: Export strong corrugated carton.
Delivery Detail: Within 7 - 10 days for container order quantity
upon confirmed invoice or sales contract.
Our Service
--Fast response: Your inquiry will be replied within 24 hours via
e-mail or online messenger;
--Technical support: You have more than 10 years experience for
product research, installation guidance, market analysis, etc.
--OEM & ODM: We welcome OEM & ODM requirements for solar collector,
storage tank, installation frame, and even for some out-sourcing
equipment;
--Sample checking: In spite of quality control in production,
samples will be selected and installed to check prior to delivery;
--Minimum order quantity: We offer sample sample manufacturing for
customers to check the quality and service;
--Shipping service: We offer to arrange goods shipment to abroad
ocean port or inland site, and if necessary to make goods
insurance, customs clearance, etc;
--Import certificates: We offer to make Certificate Origin CO, FORM
A, FORM E, FORM F, customs certification, etc.
FAQ
1. Technical support: We offer design and installation instruction
with 10 years installation experience.
2. OEM: Your LOGO information can be made on our Flat Plate Panel
Solar Collector and carton boxes.
