3 Phase Variac 10 KVA Variable Voltage Output Transformers TSGC2-15

    Buy cheap 3 Phase Variac 10 KVA Variable Voltage Output Transformers TSGC2-15 from wholesalers

    Buy cheap 3 Phase Variac 10 KVA Variable Voltage Output Transformers TSGC2-15 from wholesalers
    • Buy cheap 3 Phase Variac 10 KVA Variable Voltage Output Transformers TSGC2-15 from wholesalers

    3 Phase Variac 10 KVA Variable Voltage Output Transformers TSGC2-15

    Ask Lasest Price
    Brand Name : YOMIN
    Model Number : TDGC2
    Certification : CE, ISO, ROHS
    Price : it can negotiate
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5000 PCS/MONTH
    Delivery Time : shipped in 2-5 days after payment depends on the quantity
    • Product Details
    • Company Profile

    3 Phase Variac 10 KVA Variable Voltage Output Transformers TSGC2-15

    TSGC2 - 15 3 Phase Variac , 10 KVA Variable Voltage Output Transformers


    Product Description


    The Voltage regulators (Variac) are used to adjust the voltage from 0 volts up to the


    maximum voltage for which they have been designed and among the most usuall


    applications. No additional wave from distortion. The main applications are:

    • Laboratory control equipment.
    • Lighting equipment.
    • Temperature controls.
    • Motor speed control.
    • Controlling of other transformers.
    • Etc.

    Manually Operated Rotary Knob to control output voltage, by means of a control button on the shaft of the voltage regulator (Variac) which allows to act on the brush and achieve thedesired voltage. The voltage can be smoothly varied between turns as the brush has arelatively high resistance (compared with a metal contact) and the actual output voltage is a function of the relative area of brush in contact with adjacent windings.


    Technical parameters

    • Capacity.....................................................15000VA
    • Output Current..........................................20A
    • Output........................................................0~430VAC
    • Frequency.................................................50/60Hz
    • Input...........................................................380VAC
    • Insulation Resistance...............................>2MΩ
    • No. of Phase.............................................Three-Phase
    • Winding Material......................................100% Copper
    • Max.Temperature.....................................60℃
    • Insulation Class........................................Class B (130℃)
    • IP/NEMA Rating........................................IP20
    • Variable Operation...................................Manually Operated Rotary Knob
    • Portable Carrying Grip............................Provided
    • Pollution Rating.......................................Class III
    • Analog Voltmeter Display.......................Provided
    • Housing Material.....................................Shock-Proof Metal
    • Voltage Setting........................................Manual Control
    • Standards................................................VDE0550,IEC204-1,IEC61588,EC439
    • Sample Service.......................................Pay to Provide
    • Quality Assurance..................................18Months
    • Item Condition.........................................Brand-New

    ItemCapacity

    Input

    Voltage

    Output

    Voltage

    Output

    Current

    Case

    Qty.

    Model(kVA)(V)(V)(A)(Pcs.)
    TSGC2-1.51.53800~43022
    TSGC2-333800~43041
    TSGC2-663800~43081
    TSGC2-993800~430121
    TSGC2-10103800~430121
    TSGC2-15153800~430201
    TSGC2-20203800~430271
    TSGC2-30303800~430401
    TSGC2-40403800~430531
    TSGC2-60603800~430801
