Parker 491514Q3 D400Q3 solenoid coil insert diameter 9.5mm high 37mm AC220V 110V DC12V 12W

Parker 491514Q3 D400Q3 solenoid coil insert diameter 9.5mm high 37mm AC220V 110V DC12V 12W

The Parker 491514Q3 D400Q3 solenoid coil is used to parker series solenoid valves, which insert diameter 9.5mm,

Specifications:

• Heat resistant bobbin moulded with 30% glass filled thermoplastic polyester material
• Class H wire 200°C according to IEC 317-13
• Built-in magnetic yoke made by low carbon iron
• Encapsulation with high quality specially designed glass filled nylon ( thermoset material on demand for 22 mm coil ).
The use of other materials is possible upon special agreements. All coils are rated to class F and to IP 65 ( with connector ).
The coil is designed and constructed in accordance to EN 60204.1 and VDE 0580 and it is suitable for industrial ambient conditions. For use in special ambients with high humidity, we suggest the sealed or thermoset version.

Drawings:

Operator :

Note:

Competitive Advantage:

1. Professional workshops

2. High and stable quality

3. Quick delivery time

4. Good package in order to void the problems in transportation.

5. Best service from the whole company.
