    CQUY2600 Hydraulic Crawler Crane Light Weight 242kw 254t High Rigidity Durable

    Ask Lasest Price
    Brand Name : SINOVO
    Model Number : CQUY2600
    Certification : CE
    Payment Terms : T/T, L/C
    Delivery Time : STOCK
    Supply Ability : 30 units per month
    • Product Details
    • Company Profile

    CQUY2600 Hydraulic Crawler Crane Light Weight 242kw 254t High Rigidity Durable

    CQUY-2600 Hydraulic Crawler Crane Light Weight 242kw 254t High Rigidity Durable


    Technical characteristics of CQUY2600


    Using own lifting system can realize the dismantling function of track , counter-weight and boom . it owns convenient transporation , which shortens installation time , and saves users'time greatly.


    Power system conforms to Europe III emission standard imported cummines engine, energy conservation and enviromental protection .The main pump, motor, reducer,etc use germant rexroth products to ensure that the products are high relliability .


    Boom frame is welded by high rigidity steel pipe which is imported , and its light weight ,high rigidity and load bearing make crawler crane working condition much better.


    Using the high performance moment limiter , installing camera, anemometer , level and winch monitoring system to display and monitor work state timely .Installation turn-table rotary locking device ,boom prevention tilting device , winding preventing over-wind , prevent discharge and other safety to ensure the safety and reliability of the machine .


    Can pitch in the cab, with wide vision and configuration of high -grade seat , air conditioning system , car DVD system , the operation is comfortable .


    With heavey main arm , weight mixed main arm , auxiliary arm and tower vice arm and arm frame combination .


    Technical data
    ITEMCQUY2600
    Max hoisting weiht :Main boom260t
    Max hoisting weiht :Auxiliary boom25t
    Max hoisting torque1300(t.m)
    The main boom length15.2-90.4(m)
    Fixed auxiliany boom length13-36(m)
    Max length of main boom+auxiliary boom66.2+36(m)
    Max length of main boom+ tower auxiliary boom54.2+61(m)
    The main boom angle30-80º
    Wire rope speed (hositing )136(m/min)
    Wire rope speed (Dscending )136(m/min)
    slewing speed1.7(r/min)
    Travelling speed1.2(km/h)
    Grade ability30%
    Counterweight quality88t
    Grounding pressure0.114(Mpa)
    Engine power242kw
    Gross weight254t
