Quick Turn PCB Fabrication , Electronics PCB Components Assembly
Testing
PCB Assembly capability and services:
1. One station Turnkey PCB Assembly for various Electronic products
2. Professional Surface-mounting and Through-hole soldering
Technology
3. Various sizes like 1206, 0805, 0603, 0402, 0201 components SMT
technology
4. ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
5. PCB Assembly With UL,CE,FCC,Rohs Approval
6. Nitrogen gas reflow soldering technology for SMT.
7. High Standard SMT and DIP Assembly Line
8. High density interconnected board placement technology capacity.
Design file format:
1. Gerber RS-274X, 274D, Eagle and AutoCAD's DXF, DWG
2. BOM (bill of materials)
3. Pick and place file (XYRS)
Advantages:
1. Turnkey manufacturing or quick-turn prototypes
2. Board-level assembly or complete system integration
3. Low-volume or mixed-technology assembly for PCBA
4. Even consignment production
5. Supoorted capabilities
Detailed Specification of Pcb Assembly
1 | Type of Assembly | SMT and Thru-hole |
2 | Solder Type | Water Soluble Solder Paste,Leaded and Lead-Free |
3 | Components | Passives Down to 0201 Size |
BGA and VFBGA |
Leadless Chip Carries/CSP |
Double-Sided SMT Assembly |
Fine Pitch to 08 Mils |
BGA Repair and Reball |
Part Removal and Replacement-Same Day Service |
3 | Bare Board Size | Smallest:0.25x0.25 Inches |
Largest:20x20 Inches |
4 | File Formats | Bill of Materials |
Gerber Files |
Pick-N-Place File(XYRS) |
5 | Type of Service | Turn-Key,Partial Turn-Key or Consignment |
6 | Component Packaging | Cut Tape |
Tube |
Reels |
Loose Parts |
7 | Turn Time | 15 to 20 days |
8 | Testing | AOI inspection |
X-Ray inspection |
In-Circuit testing |
Functional test |
