    Infinity Trinocular Inverted Phase Contrast Microscope DIC Bright Field A19.0204

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Model Number : A19.0204
    Certification : CE
    Price : FOB $1~1000, Depend on Order Quantity
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    Delivery Time : 5~20 Days
    • Product Details
    • Company Profile

    Infinity Trinocular Inverted Phase Contrast Microscope DIC Bright Field A19.0204

    Infinity Trinocular DIC Bright Field Inverted Phase Contrast Microscope A19.0204


    A19.0204 Inverted DIC Contrast Microscope, Newly Designed in 2014.

    It is new type of multi-functional optical instrument. It is designed with fasion outlook and convenience operation. The phase contrast device can be attached to the light path to perform transmitted pahse contrast microscopic observation, such as phase contrast, modulation contrast, and bright field view. This unit is suitable for the microscopic observation of cells, tissues and clear liquid tissues, and the dynamic microsopic observation fo tissues cultured ina culture dish. It is applicable to scientific research institutions, colleges, and universities, medical and health, inspection and quarantine agencies, agricultural, animal husbandry and dairy industries.

    DIC Contrast, equiped with high quality DIC objectives, and split DIC slide to divid polarizing light into O/E lights, after transmit the object, combine the O/E light with small optical path difference to creat interfered image, make high contrast, 3-D images under microscope.

    --DIC Contrast, With DIC objective, DIC Split Slide, DIC Combine Slide
    --Long Working Distance Condenser For DIC Observation
    --Three Culture Dish Holder For Different Size Culture Dish
    --Photo Adapter On Left Side Of Main Body, 100% Light Pass For Low Light Photography Condition


    A19.0204 Inverted Modulation Contrast Microscope, DIC
    MagnificationTotal 100~400x
    SystemInfinity Optical System
    Mechanical Tube Length : ∝
    Conjugate Distance: ∝
    Head
    Trinocular Head, 45° Inclined, Interpupillary Distance 53~75mm
    Eyepiece

    WF10x/22mm Wide Field, Eyepiece Tube Dia. 30mm, Parfocal Distance 10mm

    Centering Telescope Eyepiece 10x
    NosepieceQuintuple
    ObjectiveLWD Infinity Plan Bright Field Objective
    10x/0.25, W.D. 4.3mm, Cover Glass Thickness 1.2mm
    DIC Contrast Objective
    10x/0.25, W.D.20.2, No Cover Glass
    20x/0.35, W.D.6.0, Cover Glass Thickness 0mm
    20x/0.40, W.D.8.0, Cover Glass Thickness 1.2mm
    40x/0.60, W.D.3.5 , Cover Glass Thickness 1.2mm
    For DIC Contrast View, To Check No Cover Glass or Thin Cover Glass Slide, Culture Dish Object Transmit Observation
    Working StageMechanical Stage 227*208mm, Glass Round Stage Dia. 118mm, Moving Range 77*134.5mm, Moving Stage Detachable
    Culture Dish Holder 1, 86mm (W)*129.5 (L), For Circular Culture Dish Dia.87.5mm
    Culture Dish Holder 2, 34mm (W)*77.5 (L), For Circular Culture Dish Dia.68.5mm
    Culture Dish Holder 3, 57mm (W)*82mm (L)
    FocusingCoaxial Coarse & Fine Focus Knob, With Tension Adjustable And Limit Stopper, Minimum Division 0.002mm
    CondenserLong Working Distance 55mm, N.A. 0.3.For DIC Contrast View
    Light SourceHigh Light 5W LED White, Input 3.9~3.0V , Brightness Adjustable
    Optional Accessories
    AdapterCCD Adapter 0.5xA55.0202-04
    Digital SLR Camera Adapter for Canon EF SeriesA55.0204-02
