Convenient Energy-efficient Pneumatic Air Screw Driver RC-5SS

    Buy cheap Convenient Energy-efficient Pneumatic Air Screw Driver RC-5SS from wholesalers

    Buy cheap Convenient Energy-efficient Pneumatic Air Screw Driver RC-5SS from wholesalers
    • Buy cheap Convenient Energy-efficient Pneumatic Air Screw Driver RC-5SS from wholesalers
    • Buy cheap Convenient Energy-efficient Pneumatic Air Screw Driver RC-5SS from wholesalers
    • Buy cheap Convenient Energy-efficient Pneumatic Air Screw Driver RC-5SS from wholesalers

    Convenient Energy-efficient Pneumatic Air Screw Driver RC-5SS

    Ask Lasest Price
    Brand Name : Fly
    Certification : CE
    Model Number : RC-5SS
    Price : USD25-30
    Delivery Time : within 1-30 working days after payment
    Payment Terms : T/T , paypal, Western Union,Credit card
    Supply Ability : 1000pcs
    • Product Details
    • Company Profile

    Convenient Energy-efficient Pneumatic Air Screw Driver RC-5SS

    Convenient Energy-efficient Pneumatic Air Screw Driver RC-5SS

    specification:

    1.Capacity...................................:Screw Dia.2.5~4MM

    2.Lock Torque.............................:4-16kg/cm

    3.Free Speed..............................:1200RPM

    4.Total Length.............................:230mm

    5.Weight......................................:670g

    6.Air Consumption.......................:0.2M³/min

    7.Recomm.Air Pressure................:6kg/cm²


    Instructions:

    1.Torque Control,Turning for Pre Set Torque

    2.Push-to-Start

    3.Easy Reverse



    NO.DescriptionQuantityNO.DescriptionQuantity
    1Front Housing123Valve-stem1
    2Bushing124O-Ring1
    3Ball Collar125Steel Ball1
    4Steel Ball126O-Ring2
    5Anvil128Steel Ball1
    6Washer129Spring1
    7Spacer130O-Ring1
    8Hammer Pin231Pin1
    9Hammer Dog232Reverse Knob1
    10Hammer Cage133Pin1
    11Hammer Cam134Switch Lever1
    12Washer135Pin1
    13Nut140O-Ring1
    14Bearing141Air Inlet1
    15Front End Plate142Hanger1
    16Rotor Blade643Switch set1
    17Rotor146Air Regulator1
    18Cylinder147Retaining Ring1
    19Pin148Washer2
    20Rear End Plate149Ball Retainer1
    21Bearing150Steel Ball1
    22Housing151Spring1
    Quality Convenient Energy-efficient Pneumatic Air Screw Driver RC-5SS for sale
