12m 300kgs Outdoor Mobile Platform Lift for Man Aerial Working 4
Wheels Mobile Work Platform:
Product Description:
Application:
1. It can be moved conveniently, and has bigger platform, bigger
lifting capacity to take several people to work on it together.
2. This type mobile platform lift is widely used for aerial work,
decoration, street lamp maintenance and building cleaning etc.
Model | Capacity | Table size | Max height | Work height | Total dimension | Net weight |
SJY0.3-4 | 300Kgs | 1500×750mm | 4m | 5.7m | 1850×900×1900mm | 400Kgs |
SJY0.3-6 | 300Kgs | 1500×750mm | 6m | 7.7m | 1850×900×1970mm | 650Kgs |
SJY0.3-8 | 300Kgs | 1650×1000mm | 8m | 9.7m | 2100×1200×2460mm | 1200Kgs |
SJY0.5-8 | 500Kgs | 1980×1220mm | 8m | 9.7m | 2500×1550×2380mm | 1400Kgs |
SJY0.8-8 | 800Kgs | 2000×1220mm | 8m | 9.7m | 2600×1550×2640mm | 1700Kgs |
SJY0.3-10 | 300Kgs | 2100×1220mm | 10m | 11.7m | 2700×1550×2380mm | 1500Kgs |
SJY0.5-10 | 500Kgs | 2100×1220mm | 10m | 11.7m | 2700×1550×2380mm | 1600Kgs |
SJY1.0-10 | 1000Kgs | 2220×1220mm | 10m | 11.7m | 2820×1720×2850mm | 2380Kgs |
SIY0.3-12 | 300Kgs | 2550×1500mm | 12m | 13.7m | 3150×1860×2850mm | 2580Kgs |
SIY0.5-12 | 500Kgs | 2550×1500mm | 12m | 13.7m | 3150×1860×2850mm | 2780Kgs |
SJY1.0-12 | 1000Kgs | 2600×1500mm | 12m | 13.7m | 3200×2015×3090mm | 3580Kgs |
SJY0.3-14 | 300Kgs | 2990×1600mm | 14m | 15.7m | 3600×2000×2850mm | 3000Kgs |
SJY0.5-14 | 500Kgs | 2990×1600mm | 14m | 15.7m | 3600×2000×2850mm | 3200Kgs |
SJY0.3-16 | 300Kgs | 3230×1600mm | 16m | 17.7m | 3700×2000×3030mm | 3900Kgs |
SJY0.3-18 | 300Kgs | 3230×1600mm | 18m | 19.7m | 3700×2000×3250mm | 4500Kgs |
SJY0.3-20 | 300Kgs | 3230×1600mm | 20m | 21.7m | 3700×2000×3450mm | 5100Kgs |
Parts Show:
Configuration:
1) Platform Material:120mm*60mm rectangular tube +6mm checkered
iron
2) Scissor material: 160mm*80mm*6mm high strength Manganese Steel.
3) Hydraulic system: 380V/3.0Kw
4) High Precision Hydraulic Cylinder: 90*4sets
5) Piston Rod: 50*4 hard chromium plating surface.
6) High-pressure oil pump
7) Hydraulic oil: summer 46#, winter 32#
8) Controller: 1 control box below, 1 control panel above platform
Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency
occurs.
2) The safety rails to guarantee safety of the people above work
platform.
3) The limit switch system helps the mobile platform lift to stop at accurate position.
4) Electricity leakage protection device is equipped on, all
electric components are CE certified.
5) All the mobile platform lift are passed 1.2 times loading test before leaving factory.
The workshops:
Packing and delivery:
The customers visiting:
The Certificates:
Our Services:
1) We can design the customerized mobile scissor lift as per your requirement.
2) The most suitable mobile scissor lift will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and
maintenance.
6) Two year warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human
factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or
other communication online.
9) We could reply you in 2 hours after received your any questions
even on weekend and holiday.
Engineers are available to your country if necessary.
