    Woodworking Machining CO2 Laser Engraving Machine 60w / 80w / 100w / 130w / 150w CO2 13090 3D Crystal

    Ask Lasest Price
    Brand Name : Perfect Laser
    Model Number : PEDK-13090
    Certification : CE / ISO / FDA / SGS / TUV
    Price : Negotiable
    Payment Terms : T/T, L/C, PayPal, Western Union
    Supply Ability : 3000 Unit per Month
    Delivery Time : 5-10 Working Days
    • Product Details
    • Company Profile

    Woodworking Machining CO2 Laser Engraving Machine 60w / 80w / 100w / 130w / 150w CO2 13090 3D Crystal

    Woodworking Machining CO2 Laser Engraving Machine

    60w / 80w / 100w / 130w / 150w CO2 3D Crystal

    (Model:PEDK-13090)

    ※Product Introduction


    PEDK-13090 laser engraving machine is the most hot-selling model accepted by our customers. Co2 laser cutters has large 1300mm by 900mm working area, compact nesting, convenient storage materials.The knife-shape aluminum heavy strip work of the platform can avoid defective products caused by reflection of backstop while cutting acrylic & wood materials.If change into honeycomb working table, Co2 laser cutters can used to engrave and cut cloth, fabric, carpet, shoes, etc.



    Product Feature


    1. Professional Working Table: Honeycomb or Strip work table of the 80w laser cutter for you to choose, use imported stable aluminum material, can meet the needs of diversified laser procession.

    2. Taiwan Made Ball Screw Rod: The motorized up and down table adopt Taiwan “Double-win” brand high precision ball screw rod and high accuracy linear running guide rail, can improve the precision and accuracy of the 100w laser cutter.

    3. Red Light Pointer Function: As laser light is invisible, and the red light pointer of the pvc laser cutter can realize the exact position of laser beam.

    4. Special Front and back running-through design 30-50mm height, Co2 laser cutters can make a unique door for the limitless engraved materials come through from front into back side, easy to put material through.

    5. Ladder-Shape Drawer Design: Easily collect and getting the cutting object.

    6. Laser Beam Stop when Opening Machine Cover: We design a special function to stop the laser beam come out when operator open the 130w laser cutter machine’s cover. So that ensure operator won’t be hurt by laser beam, safe for operator. Other company don’t have such design, so it will hurt operator sometime when using it.

    7. We Do Strict Testing for Each Laser Tube: We will test every laser tube before using them, in order to make sure the performance of laser tube and it has nice laser facular.

    Comparison of advantages with other machines

    Application


    1. Available materials

    the Co2 laser cutters are widely applied in acrylic, organic glass, wood, MDF, textile, fabric, cloth, leather, paper, EVA materials, PVC plastic, crystal, bamboo, seal, rubber plate, marble, granite, Gum, Ceramics, etc. nonmetal materials.

    2. Application Industry

    the Co2 laser cutters are widely applied in advertisement, arts and crafts, toys, car, mechanism, electron, as well as in trademarks, embroidery, clothing and other industries.


    ※Technical Data


    Working Area1300x900mm (4 feet*3 feet) Co2 Laser Cutters
    Laser Power60w / 80w / 100w / 130w / 150w
    Laser TypeHermetic and Detached Co2 Laser Tube
    Engraving Speed0-60000mm/min
    Cutting Speed0-10000mm/min
    Cutting Thickness0-25mm acrylic (Others Determined by Materials)
    Repeat Location Accuracy+/-0.0125mm
    Driving ModeDC0.8A 24V Stepper Motor
    Position SystemRed dot Laser Pointer
    InterfaceUSB port transfer
    VoltageAC220v/50hz or 110v/60hz
    Machine Power900w
    Controlling SystemCNC Professional Control System
    Support Graphics ModeBMP,HPGL,JPEG,GIF,TIFF,PCX,TAG,DST, PLT,DXF etc.
    Cooling ModeCW-3000 Water Cooling (with Protection Function)
    Auxiliary DevicesExhaust Fan and Exhaust Pipe
    Cutting PlatformProfessional Thickening Strip or Honeycomb Work Table
    Power Control ModeLaser Energy Combining Movement Control System
    SoftwareProfessional Reader Laser Cutting Software
    Operating Temperature0-45C
    Operating Humidity5-95%
    PackingWooden Box
    Guarantee Time12 Months for Machine, 3-10 Months for Laser Tube
    OperationVCD Training, Engineer Overseas Available
    Machine Size1970mm*1480mm*1250mm

    Packaging & Delivery


    1. Prompt deliver at the very day.
    2. Sophisticated and professional logistic agent.
    3. Well-trained and disciplined packing team.
    4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.


    Competitive Advantages


    1. We offer high quality products at competitive price in quick delivery.
    2. 100% custom pass guaranteed.
    3. Good after-sale service.
    4. Flexible and Untraceable payment terms.
    5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.

    Quality Woodworking Machining CO2 Laser Engraving Machine 60w / 80w / 100w / 130w / 150w CO2  13090 3D Crystal for sale
