    Motorized Hinge Door Autoclave Steam Sterilizer With Silicone Gasket

    Ask Lasest Price
    Brand Name : Medpharm
    Model Number : MDB-0.6
    Certification : CE / ISO
    Price : negotiation
    Payment Terms : T/T in advance/LC AT SIGHT
    Supply Ability : 10 pcs per month
    Delivery Time : 30 working days after received your payment
    • Product Details
    • Company Profile

    Motorized Hinge Door Autoclave Steam Sterilizer With Silicone Gasket

    Motorized Hinge Door Autoclave Steam Sterilizer With Silicone Gasket


    Key features:


    • Mirror polished (<20Ra) chamber and door with "easy-clean" rounded corners and

    floor-sloping drain system.

    • High temperature FDA approved silicone door seal.

    • Non-proprietary components for all plumbing, electrical and control systems.

    • Industrial grade pneumatic valves provide high reliability and low maintenance costs.

    • Guaranteed chamber temperature control of +/- 0.5 oC.

    • Guaranteed chamber temperature distribution of +/- 1.0 oC.

    • Chamber drain line condensate level sensor system.

    • Ethernet communications for remote data acquisition capability for option.

    • Automatic temperature and pressure instrument calibration function.


    Description:


    Our pharmaceutical autoclaves are designed and manufactured in a state of the art facility in

    compliance with cGMP regulations to meet the technical challenges of pharma and biotech

    industries.


    Pharmaceutical autoclaves provide precise control and reliable sterile processing. We provide high quality & safe autoclaves made from reliable long lasting components, and designed to conform to end user requirements (URS) for production and quality assurance processes.


    Specification:


    Model

    MDB-0.6

    Door type

    Motorized Hinge Door ,single door

    Chamber volume and size

    600L , 610*910*1170mm

    Overall Size

    1450*1900*1510mm

    Net Weight

    1250kg

    Steam

    30Kg/cycle

    Water

    70Kg/cycle

    Power(KVA)

    3KVA

    Sterilization temperature rage

    105°C to 134°C

    Sterilization time rage

    0---99 minutes

    Vacuum times

    0---9 times

    Drying time

    0---99 minutes

    Main components

    SS304 built-in steam generator

    Touch screen display

    PLC control system

    High effective liquid-ring vacuum pump


    Materials for different choice:


    MATERIALS are important for autoclaves

    The chamber and jacket are manufactured in various grades of stainless steel.


    Many sterilizer pressure vessels fail from pitting and stress corrosion cracking

    as a result of poor water quality in the steam generators.


    Medpharm autoclaves incorporate an automatic blow down feature into its steam generators
    which reduces this risk and makes the use of high quality materials such as 316L.


    However we can supplied on requests in order to meet client’s individual requirements or tender specifications.


    Chambers are electro-polished to give a high quality surface finish.


    Chamber

    STEEL


    304 L stainless steel

    STANDARD

    316 L stainless steel


    Jacket

    STEEL


    304 L stainless steel

    STANDARD

    316 L stainless steel


    Door internal side

    STEEL


    304 L stainless steel

    STANDARD

    316 L stainless steel




    Brochure unload here


    Medpharm medical large steam autoclave brochure.pdf
