    EN Environmental Test Equipment Bicycle Cpmprehensive Durability

    Ask Lasest Price
    Brand Name : Haida
    Model Number : HD-1052
    Price : USA2500-6000/set
    Payment Terms : L/C, D/P, D/A, T/T, Western Union, MoneyGram
    Supply Ability : 300sets/month
    Delivery Time : 15 Days after oder.
    • Product Details
    • Company Profile

    EN Environmental Test Equipment Bicycle Cpmprehensive Durability

    En Environmental Test Equipment Bicycle Cpmprehensive Durability


    Product Description

    Introduce:


    EN Bicycle Cpmprehensive Durability Testing Equipment Price is suitable to test bike’s run test& brakes performance test. T


    EN Bicycle Cpmprehensive Durability Testing Equipment Price is formed by two rollers with varied diameter and follows specification to install jump plates at bike’s seat post. pedals, bars, luggage carries, with load set to this tester.


    Adjust the distance between front and rear wheel base on the standard for complete cycles, constantly rotate the wheel is by 7-27km/hr and the bike is supposed to maintain its normal function, no part damage or crack is found. For brake test, follow the specification specified roller’s friction coefficient, wind speed and water-spray amount of loaded brake & handlebars to test the performance


    Designed standard:

    EN14764, EN14765 (City and trekking bicycle Part 4, Bicycle for young children Part 4)


    Main technical:

    Model

    TT-1052DB

    TT-1052B

    TT-1052D

    Brake & run test

    Brake test

    Run test

    Adjust range between front & rear wheels

    mm

    860~1200/(600~1200 optional) / Customer specified

    Counter setting

    diameter

    760/(560 optional ) / Customer Specified

    Jump block amount& combination phase

    EN14764 standard

    EN14764 standard

    power

    Servo Motor + reducer + Clutch

    AC Reduce Motor+ speed Regulation+ clutch

    Testing speed(km/hr)

    7-26km/hr(special speed-upon request)

    Crank Drive Mechanism(optional)

    Testing speed(km/hr)

    7-26km/hr(special speed-upon request)

    Counter Weight

    Seat Post(Kg)

    36

    Overall Weight 120

    Pedals(Kg)

    18

    Handlebar(Kg)

    6.75

    Luggage Carriers(Kg)

    10.18.25.according to luggage carriers, area 204X240(Assembly Type)

    Head Tube(Kg)

    14

    Force to Brake Handlebars

    ConformEN14764 Standard(Auto weight 40~180N)

    Brake Force

    Brake Force(N)

    700

    ±1

    N/A

    Resolution

    N/A

    Accuracy

    N/A

    Power

    3;220V;50HZ(3;380V optional)

    Consumption

    KW

    10

    5

    8

    Dimension(WxDxH)

    3030x1200x2900mm (Ref Only)

    Standard Accessories

    Tool Kitx1, Operational Manual in English x1, Testing dead weigh, Warranty Certificationx1


    Brake test velocities and braking distance:

    Ref: (EN14764)

    Condition

    Velocity(Km/h)

    Brakes in use

    Braking distance

    Dry

    25

    both

    7

    Real only

    15
