    LTD800 Hoist Wind Tower Production Line Safety For Working Platform

    LTD800 Hoist Wind Tower Production Line Safety For Working Platform


    Friendship Machinery "LTD80" Electric Traction hoist designed to be used with unlimited rope lengths for lifting and lowering personnel. Capacities 800kg at 9.3m/min.


    The Friendship Machinery LTD80 hoist is versatile and suitable for unlimited applications.


    The rope is not connected so it’s compact, lightweight and very easy to handle. The unrestricted wire rope lengths capability of the LTD hoist makes it possible to utilize unlimited lifting heights and traction lengths.


    1. Safety


    In the event of a power failure, the electric-mechanical brake can be manually released in order to ensure safe and controlled lowering of the load. Safe lowering mechanism is guaranteed by the integrated centrifugal force brake


    2. Features and Benefits


    - The robust and strong die-cast aluminum casing with low dead weight
    - Gearing and drive sheave are fabricated from hardened steel.
    - Motor and connection box protection class IP55.
    - Hoist motor is fitted with a thermal overload protection device.
    - Standardized components ensures easy access to all wearing parts.
    - The parameters of LTD series hoist
    - Rated Lifting Force: 8kN
    - Lifting Speed: 9.3m/min
    - Voltage: 380V(415V/220V)
    - Frequency: 50Hz/60Hz
    - Power: 1.8kw
    - Dimension: 310×250×600mm
    - Weight: 52kg
    - Braking Torque: 15N.m
    - Rotate Speed: 1400r/min
    - Diameter of Wire Rope: 4×31SW+FC-9.1mm
    - Voltage and frequency is available upon request
