    Easy Use Customize Tile Roll Forming Machine with Good Reputation

    Ask Lasest Price
    Brand Name : Shenghong
    Model Number : SWL151222-105
    Certification : CE ISO
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 25 SETS/ MONTH
    Delivery Time : 40 days after payment
    • Product Details
    • Company Profile

    Easy Use Customize Tile Roll Forming Machine with Good Reputation

    Easy Use Customize Tile Roll Forming Machine with Good Reputation


    Technical parameter


    Controller
    We choose Mitsubishi PLC from Japan.
    With touch screen mode, let your workers enjoy the easy operation;
    With auto working mode, let your workers free their hands!


    ItemSpecification

    Raw Material
    TypePre-painted steel coil & galvanized coils
    Thickness(mm)0.3-0.7
    Yield strength(mpa)235-550
    Roller material45# steel , coated with Chrome
    Shaft for rollersSolid shaft with 72mm,processed with cylindrical grinder
    Forming speed(m/min)About 20-25
    Output speed(m/min)About 12 for 6m length sheet
    Speed adjusting modeMitsubishi frequency transformer
    Roller driveDecelerating motor + Chain drive
    Cutting modeHydraulic cutting
    Cutter materialCr12 mould steel
    Length measurementNemicon Encoder
    Control modeMitsubishi PLC
    Operating modeButton + Mitsubishi Touch screen
    Main motor power(kw)7.5KW
    Total power(kw)9.9 KW


    Components of machine


    Decoiler (manual decoiler and hydraulic decoiler for option)1set
    Feeding & guiding device1set
    Main roll forming machine1set
    Hydraulic cutting system1set
    Controlling system1set
    Run out table (auto. Stacker for option)1set

    We customize your machines! To customize machine, we would love to know:


    1. Profile drawing
    2. Raw material: the width(1250mm?), thickness(0.3-0.7mm?), and yield strength of steel coil.
    3. Voltage: designed per your requirement
    4. Configuration requirement: Hydraulic or manual decoiler/ stacker

    Have no idea about them?
    We will be glad to recommend the lacal popular profile for you----Just let us know your country!


    Packing


    1. One 40feet container for loading one set machine with mechanical decoiler.
    2. Main machine body and decoiler is load naked (tighten to container with steel wire rope).
    3. Spare parts and operating tools are loading in tooling box.

    Delivery : about 40-50 days after received advanced payment


    Why us?


    1. Customize roll forming machines since 2010.
    2. Capacity: 25 sets / month
    3. Delivery: in only 5-8 weeks for urgent order
    4. Company occupies 6650, in which 5650 for workshops
    5. Have our own tool center. 12 sets CNC machines.
    6. Technician can be sent to your factory to install the machine and train your workers

    Process flow


    Decoiler -- Feeding & Guiding -- Roll forming---Hydraulic Cutting - product to run out table


    Machinery Photos



    Workshop Show


    Get Free:
    Provide profile drawing & design technical support FOR FREE!
