    ASTM A249 S30409 304H Stainless Seamless Steel Tubes For Boiler

    Ask Lasest Price
    Brand Name : TOBO/TPCO/TISCO/VALIN/METAL
    Model Number : ASTM A249 S30409 304H
    Certification : ISO/PED/TUV/SGS/LR/BV
    Price : negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 50000tons/year or stocks
    Delivery Time : 15days->
    • Product Details
    • Company Profile

    ASTM A249 S30409 304H Stainless Seamless Steel Tubes For Boiler


    ASTM A249 S30409 304H Stainless Seamless Steel Tubes For Boiler

    Quick Details

    Standard:
    ASTM, ASTM A312-2001, ASTM A312-2007, ANSI A312-2001
    Thickness:
    1.65 - 25.4 mm
    Section Shape:
    Round
    Outer Diameter:
    0.5 - 48 inch
    Place of Origin:
    Shanghai, China (Mainland)
    Secondary Or Not:
    Non-secondary
    Application:
    Boiler Pipe
    Technique:
    Hot Rolled
    Certification:
    DIN
    Surface Treatment:
    As customer's requirement
    Special Pipe:
    Thick Wall Pipe
    Alloy Or Not:
    Non-alloy
    STAINLESS STEEL PIPE:
    STAINLESS Seamed tube 1 1/2" SCHEDULE 40 SA-312

    Packaging & Delivery

    Packaging Details:In bundles or according to requirements of customers
    Delivery Detail:7~25 Days

    Specifications

    1.MTC is supplied together with the pipe
    2.Any third party inspection is acceptable
    3.Do business based on mutual benefit

    Specialized excellent stainless STEEL Pipe 312
    KEY WORDS: sa312 tp304/ STAINLESS Seamed tube 1 1/2" SCHEDULE 40 SA-312/ Seamless SA312 TP304 stainless steel pipes/ welded steel tube SA312 TP304 / 304H/ sa312 tp304 seamless pipe/ 304 stainless steel pipe/ ASTM TP 304 Stainless Steel Pipe price per kg

    1. Tolerance

    1:Outerdiameter:+-0.05mm 2:Thickness:+-5% 3:Length:+-0-4.5mm

    2. Wall thickness

    0.3-11 mm

    STAINLESS STEEL PIPE

    Standard:

    ASTM A312/A312M 05a--Standard of American Society for Testing
    &Materials

    ASTM A269 04--------- Standard of American Society for Testing &Materials

    Application:

    ASTM A312/A312M 05a

    ASTM A312/A312M 05a is used for general corrosive and low-or high-temperature condition service

    ASTM A269 04

    ASTM A269 04 is used for high-temperature and general corrosive condition service

    Main Steel Tube Grades:

    TP304,TP304L,TP321,TP316,TP316L,TP347,TP347H

    Other Grades can also be provided after consulting with customers.

    Chemical Compositon

    Steel Grade

    Chemical Composition (%)

    C

    Mn

    P

    S

    Si

    Cr

    Ni

    Mo

    TP304

    0.08

    2

    0.045

    0.03

    0.75

    18.0-20.0

    8.0-11.0

    /

    TP304L

    0.035

    2

    0.045

    0.03

    0.75

    18.0-20.0

    8.0-13.0

    /

    TP304H

    0.04-0.10

    2

    0.045

    0.03

    0.75

    18.0-20.0

    8.0-11.0

    /

    TP316

    0.08

    2

    0.045

    0.03

    0.75

    16.0-18.0

    11.0-14.0

    2.00-3.00

    TP316L

    0.035

    2

    0.045

    0.03

    0.75

    16.0-18.0

    10.0-14.0

    2.00-3.00

    TP316H

    0.04-0.10

    2

    0.045

    0.03

    0.75

    16.0-18.0

    11.0-14.0

    2.00-3.00

    TP321

    0.08

    2

    0.045

    0.03

    0.75

    17.0-19.0

    9.0-12.0

    /

    TP347

    0.08

    2

    0.04

    0.03

    0.75

    17.0-20.0

    9.0-13.0

    /

    TP347H

    0.04-0.10

    2

    0.04

    0.03

    0.75

    17.0-20.0

    9.0-13.0

    /

    Mechanical Properties

    Steel Grade

    Mechanical Properties

    (MPa)
    Tensile Strength

    (MPa)
    Yield Strength

    (%)
    Elongation

    TP304

    ≥515

    ≥205

    ≥35

    TP304L

    ≥485

    ≥170

    ≥35

    TP304H

    ≥515

    ≥205

    ≥35

    TP316

    ≥515

    ≥205

    ≥35

    TP316L

    ≥485

    ≥170

    ≥35

    TP316H

    ≥515

    ≥205

    ≥35

    TP321

    ≥515

    ≥205

    ≥35

    TP347

    ≥515

    ≥205

    ≥35

    TP347H

    ≥515

    ≥205

    ≥35


    Steel Grade:

    304/304L(1.4301/1.4306);316/316L(1.4401/1.4404);316Ti(1.4571); 321(1.4541);310S(1.4845); 317L(1.4438);321H(1.4878); 304H(1.4948); 347/347H(1.4550/1.4551);2205(1.4462);904L(1.4539);UNS31803(SAF2205/1.4462),SAF2507(S32750/1.4410)

    Outside Diameter:6 – 630mm(1/4" – 25")
    Wall Thickness:1 - 50mm
    Standards(Norm)EN 10216-5;DIN 17456;DIN 17458
    GB/T14975;T14976;T13296;GB5310; ISO2037
    ASTM A 312;A269;A213;A511;A789;A790;
    JIS G3459;G3463;
    GOST 9940;GOST 9941;
