| Brand Name : | Altrasonic |
| Model Number : | HSS59B-ZB |
| Certification : | CE |
| Price : | negotiation |
| Payment Terms : | T/T |
| Supply Ability : | 1000pcs per month |
| Delivery Time : | 10 working days after received your payment |
High Pressure Ultrasonic Sonochemistry , Ultrasonic Cell Crusher
35Kg CE
Specifications:
| Model | HSS11B-EB | HSS17B-ZB | HSS57B-ZB | HSS59B-ZB | HSS61B-ZB |
| Frequency | 40±1 KHz | 20±1 KHz | 20±1 KHz | 20±1 KHz | 20±1 KHz |
| Power | 100 W | 1000 W | 1500 W | 2000 W | 3000 W |
| Voltage | 220±10% V | 220±10% V | 220±10% V | 220±10% V | 220±10% V |
| Temperature | 150 ℃ | 150 ℃ | 300 ℃ | 300 ℃ | 300 ℃ |
| Pressure | Normal | Normal | 35 MPa | 35 MPa | 35 MPa |
| Intensity of sound | >10 W/cm² | >10 W/cm² | >30 W/cm² | >40 W/cm² | >60 W/cm² |
| Max Capacity | > 100M L/Min | > 5 L/Min | > 15 L/Min | > 20 L/Min | > 30 L/Min |
| Material Of Tip Head | Titanium Alloy | Titanium Alloy | Titanium Alloy | Titanium Alloy | Titanium Alloy |
The Principle of ultrasonic extraction processor:
Ultrasound of the transesterification reaction mechanism is based
on cavitation.
In the ultrasonic irradiation, the liquid flow generated thousands
of tiny bubbles, these tiny air bubbles vibrate in the effect of
sound field, when the sound pressure reaches a certain value, the
bubble rapidly growth, then bubbles burst and generated the burst
wave, so that atmospheric pressure is generated around the
thousands.
Radiation input energy is converted into frictional, waves and
cavitation, cavitation bubbles burst of negative pressure can
produce intense local high temperature ( about 5000K) and high
pressure ( about 100Mpa), accompanied by a huge cooling rate (
greater than 109K / S) and the liquid jet stream ( about 400Km /
h), and the agitation caused by the pressure of liquid can overcome
the adhesion force and the adhesive force to the reaction system in
a very short period of time to achieve better extraction.
1. Save mixing time 20%~60%
2. Lower temps 30%~60%(30 degrees C)
3. easily to do installation
4. operation in high efficience
5. Extraction of the herb and triditional medicine plants
effectively
6. Eigital generator surpporting the system; searching frequency
automatically
Other Applications:
WHY CHOOSE ALTRASONIC ?
2000W / 3000W High Pressure Ultrasonic extraction Pocessor For Cell Disruption / sonochemistry system



|
