YL10.2 Tungsten Carbide Strips for milling machine processing
a×b×L | a
(mm) | b
(mm) | L
(mm) |
a×b×L | a
(mm) | b
(mm) | L
(mm) |
| 3～8+0.2+0.4 | 1～3+0.15+0.35 | 330+0+3.0 | 14～34+0.4+0.6 | 2～5+0.15+0.35 | 330+0+3.0 |
| 8～14+0.3+0.5 | 2～5+0.15+0.35 | 330+0+3.0 | | | |
Cemented carbide strips are usually used for general wood cutters / hard wood cutters
,plastic and tobacco cutting . and meet the ISO9001:2008 quanlity
standard. We can make the shipment in the shortest delivery time
wtih the compeititve price than any other factory.
We can manufacture various cemented carbide stipes and plate as per
customer's requirments based on the differente markets. Our main
products include :Cemented carbide drills, cutting cutters, mining tools, drawing
dies ,carbide stripes ,rods etc.
Skillful workers and advanced euquipments can make every of your
size possible.
Different grade are available too.
We take great efforts to increase commodity types rather than
quantitiy to promote the flexibility of competing in the
worldmarket. Above all , our client;s demands are always the first
to be considered..
Regular Specification:
Width: 3-16, 18, 20, 22, 25, 28, 30, 32, 35, 40, 70 mm
Thickness: 1.5-6 mm
Length: 310 mm( we can cut it to different length as required.)
Grades k | Equal to
ISO | Density
(g/cm2) | TRS
(N/mm2) | Hardness
(HRA) | Application |
YG7 | K10 | 14.8 | 1950 | 90.5 | Better wear resistant than Mk6,used for hard wood used for
processing original wood,aluminum section bar,brass rod and cast
iron. |
YG6 | K10 | 14.85 | 1900 | 90.8 | Has wear resistance higher than Mk6,used for processing hard wood, original wood,aluminum section bar,brass rod and cast iron. |
YG8 | K20 | 14.7 | 1950 | 89 | Wear and percussion resistance,used for processing hard wood, soft wood ferrous and non-ferrous. |
YG8A | K20 | 14.7 | 2000 | 89.5 | Wear and percussion resistance,used for processing hard wood, soft wood ferrous and non-ferrous. |
YG10X | K40 | 14.5 | 2000 | 91 | Suitable for processing hard wood,veneer board,PCB,PVC&metals |
YG12C | K40 | 14.3 | 2500 | 87.4 | For crashing the granite, marble, cobble etc |
Applications:
Carbide strip is widely used for general wood cutters / hard wood
cutters, plastic and tobacco cutting.
And it is suitable for the production of various types of motors,
electronic progressive dies punches.
Tungsten Carbide - Main Property:
1. Excellent Hardness: 86~93 HRA, which equal to 68~81HRC;
2. Excellent hot working performance: Hardness could be remained at
60 HRC under 900~1000 ℃
3. Excellent wear resistance;
4. High cutting speed;
5. Long service life
